PART LIST — Model No. PFIVEX79011.1
Item Description
1 Main frame
2 Front stabiliser
3 Rear stabiliser
4 Handlebar post
5 Handlebar tube
6 Seat support tube
7 Seat
8 Resistance knob
9 Console
10 Pedals (R+L)
11 Cap
12 Cap
13 Bolt
14 Wave washer
15 Nut
16 Sensor cable
17 Resistance cable
18 Bolt
19 Resistance knob cover
20 Screw
21 Resistance cable
22 Wave washer
23 Bolt
24 Chuck cover
25 Round cap
26 Foam
27 Heart sensor cable
28 Knob
29 Ring
30 Plastic tube
31 Washer
32 Nylon nut
33 Washer
34 Screw
35 Pedal crank
36 Crank casing or cover
37 Casing
38 Screw
Qty. Item Description
1 39 Nut
1 40 Lock washer
1 41 Nut
1 42 Ball Bearing
1 43 Bearing holder
1 44 Screw
1 45 Ring
1 46 Nut
1 47 Nut
2 48 Large flat washer
2 49 Belt wheel
2 50 Belt
4 51 Flywheel
8 52 Flywheel axle
4 53 Bearing
1 54 Tension pulley
1 55 Bearing
4 56 Tension shaft
1 57 Tension spring
1 58 Nut
1 59 Bolt
3 60 Bolt
2 61 Flat washer
1 62 Wave washer
2 63 Wave washer
2 64 Magnet holder axle
2 65 Magnet holder
1 66 Magnet
1 67 Spring
1 68 Freewheel
3 69 Flywheel tension nut
5 70 Nut
2 71 Spacing ring
2
1
2
2
10
14
Qty.
1
1
1
2
2
2
2
2
1
1
1
1
1
1
2
1
2
1
1
2
1
2
2
2
2
1
1
8
1
1
2
2
1
