Summary of Contents for M-LOCKS Basic line Series
- Page 1 Basic line EM1620 EM2020 EM2520 EM3020 EM3520 User manual V03 EN M•LOCKS BV Vlijtstraat 40 • 7005 BN Doetinchem • The Netherlands • www.m-locks.com...
- Page 2 www.m-locks.com...
- Page 3 Symbols and signals Opening the lock Opening the lock with time delay Changing managercode (with the door open!) Adding a new code/user Delete second user Setting the time delay and opening window time8 Deleting the delay setting Replacing the battery Troubleshooting www.m-locks.com...
- Page 4 In fact it may happen that the electrostatic charge of a user exceeds the extreme value many times.That’s why we are asking you to touch the metal surface of the safe for discharging before operating the lock. Caution! Don’t forget your code, if lost, the lock can not be opened anymore! www.m-locks.com...
- Page 5 Enter the code (i.e. 1-1-1-1-1-1), after entering a right code, a double signal sounds and time delay starts. During time delay expires, the light flashes every 10 seconds. After time delay has elapsed, a double signal sounds and the open window starts. www.m-locks.com...
- Page 6 • Enter the old code For example! • Select your new personal code. Enter the new code • Enter the new code again If an incorrect code is entered on the second occasion, a long signal sounds and the old code remains valid. www.m-locks.com...
- Page 7 Open window time: The period of time in minutes during which the code can be entered a second time and the lock can be opened. Changing or deleting the time delay values can only be done in open window time. www.m-locks.com...
- Page 8 Press and hold ‘9’ until a double signal sounds. The LED will illuminate when performing the following actions: • Enter the Manager Code • Delete the delay and opening window time by entering 00 for the delay setting and 01 for the opening window time. • Enter the delay setting and opening window time again www.m-locks.com...
- Page 9 The lock does not emit an audible tone when a key is pressed. The battery is exhausted, replace the battery. See point 9. c. I have forgotten my code For security reasons, M-LOCKS does not provide a code that you can use to open your lock. Please contact your supplier. www.m-locks.com...
- Page 10 This is probably a problem with the lock bar mechanism, inside the safe door, and not a problem of the lock itself. This manual only relates to the lock and not the complete safe. Please contact the manufac- turer of the safe in order to resolve this problem. www.m-locks.com...
- Page 11 Basic line www.m-locks.com...
- Page 12 M•LOCKS BV Vlijtstraat 40 • 7005 BN Doetinchem • The Netherlands • www.m-locks.com...
- Page 13 MiniTech High security lock for safes USER INSTRUCTIONS...
-
Page 14: Table Of Contents
Scroll events on the LCD ................15 Change Master code ..................15 Manager Management .................. 15 Dynamic codes ..................... 16 Page 1 of 20 M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... -
Page 15: Important Instructions
If you fail to do so, the lock may no longer function properly and you will forfeit your right to warranty. Page 2 of 20 M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... -
Page 16: Information About Minitech
= Change keypad language = Audit = Firmware release = Time delay = Back to start menu = Master menu M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 Page 3 sales@m-locks.com - www.m-locks.com... - Page 17 The lock stores the last 5.500 operations with time, date, user and operation. The keypad stores the last 250 operations with time, date, user and operation. Never remove lock cover, this voids the warranty. M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 Page 4 IU_MiniTech_03...
-
Page 18: Open The Lock
Enter second code and the Dallas key (if set). Open the lock within OPEN THE LOCK three seconds (green led). M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 Page 5 sales@m-locks.com - www.m-locks.com... -
Page 19: Change Code
Lock setup can be performed in two different ways only when the lock is in pre-setup, through a setup Dallas key or directly through a PC connected to the keypad. M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 Page 6 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... -
Page 20: Setup Through A Dallas Key
If the lock is set to display closing code, LCD will display the CLOSING CODE message: X X X M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 Page 7 sales@m-locks.com - www.m-locks.com... -
Page 21: Block And Unblock The Lock
Any working button will produce a short beep. A damaged button will cause a long beep. LCD will display the WRONG/FAULTY message. M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 Page 8 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... -
Page 22: Change Language
Enter the audit Dallas key into the reader. If the operation is OPERATION DONE successfully performed LCD will display the message: M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 Page 9 sales@m-locks.com - www.m-locks.com... -
Page 23: Download The Audit On A Pc
0 1 – X X X X X X message: Enter Manager code. LCD will display current values: TIME DELAY OPEN WINDOW Page 10 M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... -
Page 24: Master Menu
. LCD will display the message: " hh:mm Press . LCD will display the current day of the week. ! hh:mm M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 Page 11 sales@m-locks.com - www.m-locks.com... -
Page 25: Weekly Time Lock Setting - Verify Or Delete Values
END OF LIST At the end of the list press Closing periods setting - Add new values Page 12 M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... -
Page 26: Closing Periods Setting - Verify Or Delete Values
Opening periods setting- Add new values Access the time lock menu and access the function. LCD will display OPENING PERIODS the message: SETTING M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 Page 13 sales@m-locks.com - www.m-locks.com... -
Page 27: Opening Periods Setting - Verify Or Delete Values
Download the audit on a Dallas key Use this function to download all keypad and lock events on a Dallas key. Page 14 M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... -
Page 28: Scroll Events On The Lcd
“V”: Manager installed, “_”: Manager deleted, “X”: Manager disabled. Press . If the Manager is not installed LCD will display the INSTALL? message: IU_MiniTech_03 M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 Page 15 sales@m-locks.com - www.m-locks.com... -
Page 29: Dynamic Codes
Press . LCD will display the message: ENABLE? (DISABLE?) OPERATION DONE Press to confirm. LCD will display the message: M-LOCKS BV - Vlijtstraat 40 - NL-7005 BN Doetinchem - T +31 (0)314 376 876 Page 16 IU_MiniTech_03 sales@m-locks.com - www.m-locks.com... - Page 30 Certified ISO 9001 : 2008 M-LOCKS B.V. Vlijtstraat 40 - 7005 BN Doetinchem – Netherlands - Tel. +31 (0)314 37 68 76 - E-mail: sales@m-locks.com...
- Page 31 Multi Level Software Locks EM2050 EM3050 EM3550 User manual V01 EN M•LOCKS BV Vlijtstraat 40 • 7005 BN Doetinchem • The Netherlands • www.m-locks.com...
- Page 32 www.m-locks.com...
- Page 33 Activating users with Dallas key Disabling / enabling users not active in dual mode Deleting users Deleting users in dual mode Setting the time delay and open window time8 Deleting the delay setting User audit Lock audit Replacing battery Troubleshooting www.m-locks.com...
- Page 34 By example with a lever or by turning the keypad. Please contact your safe supplier for more information about your specific situation. Caution! Don’t forget your code, otherwise the lock can not be used anymore! www.m-locks.com...
- Page 35 EM3550 / EM40450: After entering a right code, you will hear a double tone, you can now open the lock, unlock the door and open it. If the lock is not opened within 3 seconds, the lock will automatically lock again. www.m-locks.com...
- Page 36 Enter the code (i.e. 1-1-1-1-1-1), after entering a right code, you will hear a double tone and time delay starts. During time delay expires, the light flashes every 10 seconds. After time delay has elapsed, a double signal sounds and the open window starts. For example! 1 second 1 second www.m-locks.com...
- Page 37 • Enter the old code • Select your new personal code. Enter the new code • Enter the new code again If an incorrect code is entered on the second occasion, you will hear a long tone and the old code remains valid. www.m-locks.com...
- Page 38 9, you have to enter 0, to send a silent alarm. For example: Valid code 2-2-2-2-2-2, alarm will be sent by entering: 2-2-2-2-2-3. This code works as a valid code. The silent alarm is indiscernibly for an outsider. www.m-locks.com...
- Page 39 (IF MANAGER IS IN DUAL MODE) Enter a random User Code. For example! • Enter random User Code Press and hold ‘1’ until you hear a double tone. The LED will illuminate when performing the following actions: • Enter your personal Manager Code www.m-locks.com...
- Page 40 • Enter User ID 1-9 (only if more than 1 user is programmed) • Enter the User Code , hold the Dallas key to the key reader after the last digit • Enter the new User Code again again hold the Dallas key to the key reader after the last digit www.m-locks.com...
- Page 41 • Enter User ID of the user that has to be deleted The user has been deleted. To activate user again please refer to function “activate user”. DELETING USERS IN DUAL MODE (IF MANAGER IS IN DUAL MODE) Enter a random User Code. For example! • Enter random User Code www.m-locks.com...
- Page 42 In this example: 2602 for a delay of 26 minutes and an open window time of 2 minutes • Enter the delay setting and open window time again The time delay and open window values are directly activated for all codes. www.m-locks.com...
- Page 43 • Enter the delay setting and open window time again USER AUDIT Press and hold ‘7’ until you hear a double tone. The LED will illuminate when performing the following actions. Listen to tone signals! For example! • Enter the Manager Code www.m-locks.com...
- Page 44 REPLACING THE BATTERY If the lock emits a series of audible tones when opened, the battery is almost exhausted and must be replaced immediately. You may only use 9V ALKALINE Duracell, Duracell Industrial- or Energizer batteries. www.m-locks.com...
- Page 45 The lock does not emit an audible tone when a key is pressed. The battery is exhausted, replace the battery. See point 19. c. I have forgotten my code For security reasons, M-LOCKS does not provide a code that you can use to open your lock. Please contact your supplier. The lock is difficult to move and open This is probably a problem with the lock bar mechanism, inside the safe door, and not a problem of the lock itself.
- Page 46 M•LOCKS BV Vlijtstraat 40 • 7005 BN Doetinchem • The Netherlands • www.m-locks.com...
- Page 47 Pulse PRO High security lock for safes USER INSTRUCTIONS...
- Page 48 Page 2 of 24 IU_PulsePRO_05...
- Page 49 Index Information about Pulse PRO ..............4 Before use ................... 8 Pre-setup mode ................... 8 How to select a configuration ..............8 Open the lock with a standard user ............9 Managers and users open the lock with time delay if enabled....9 Open the lock with an override user ............
- Page 50 Information about Pulse PRO Using your keypad Automatic power savings: if no operation is performed for 5 seconds the keypad will automatically switch off. If a wrong operation is made, wait 5 seconds until the keypad switch off. Functions Press and hold the button corresponding to the needed function. = Change codes = Activate users = Disable/Enable users...
- Page 51 Pre Setup & Configurations When a lock is new or reset, a pre-setup mode is activated. In pre-setup mode the lock can be open simply pressing the button 1. When the bolt is opened, the output on the connector “BAT” of the lock is activated. The lock can be set through the keypad with one of the 80 different configurations which involve among other things the number of the users, the dual openings and the manager management feature.
- Page 52 Dallas i-Button A Dallas key can be associated to any user during user installation (function 1) by simply entering a Dallas key after the code has been entered. User will be identified by combination plus Dallas key. Multiple keys with the same ID can be programmed (through PC software) and can be supplied for special applications.
- Page 53 Recommendations In order to recognize which model of lock is used (analog or digital lock), a lock must be connected to the keypad before to connect a power source. It is strongly recommended to immediately change the factory codes. For security reasons, do not chose codes which could be easy to guess (e.g. 1 2 3 4 5 For your new code, do not use any personal data like birthdays or any other data, that could be derived by knowledge of your person.
- Page 54 Before use When a lock is new, time & date must be set before use otherwise a long bad sound is emitted on every opening. Please be advised that Time & Date can be set also in Pre- setup mode but only if Date format already set.
- Page 55 Open the lock with a standard user Managers and users open the lock with time delay if enabled. Enter a valid opening code. Double beep and the lock open. If time delay enabled, beep and LED flashes at two seconds intervals. To stop time delay counting press Open window is indicated by beep and LED at 1 second intervals.
- Page 56 User activation (function 1) Bolt open is requested before installing an override user. If dual mode enabled, enter valid code after the Manager code. If option Manager management enabled, the Master is enabled to perform this operation too but only for Manager codes. Press and hold until double beep.
- Page 57 Battery test (function 4) The battery test gives information about the power level of the last opening. Press and hold until double beep. Double beep if battery level good. Long beep if low battery level. Lock/keypad test (function 5) The lock/keypad test gives information about the correct communication between lock and keypad and the status of each button.
- Page 58 BOLT OUTPUT/HOLD-UP. Enter special function Factory set as “Hold up” hold-up bolt output enabled. Single beep if enabled, double beep if enabled. hold up bolt output Press 0 to enable or 1 to enable . Double beep and LED goes off. DOOR ALARM.
- Page 59 User status (function 7) Press and hold until double beep. LED remains ON. Enter Manager code. Double beep. Enter the ID of the user to check their status. Single bad sound, available or disabled. Double beep, installed. Long beep, blocked. Audit (function 7) Download the audit on the Dallas key configured through the Pulse PRO Audit software or directly on a PC with a Tecnosicurezza USB interface.
- Page 60 Download from the keypad directly to a PC: First activate the “Download extended audit” on the Audit software, then select the number of events which must be downloaded and press “Download”. Press and hold until double beep. LED remains ON. Enter a Manager code.
- Page 61 Time delay (function 9) Time delay can always be increased. In order to set up a lower time delay than the current already set, lock must be open. If lock not opened, a counting of the time delay will be started after the procedure, and the new values will be stored only at the end. Press and hold until double beep.
- Page 62 skip the next step. LED remains ON. Enter a Manager code or a Master code. Double beep. Press to enter the date. Double beep. Enter the date according to the date format selected through the special function 05 (DD/MM/YY format, MM/DD/YY format). Double beep.
- Page 63 01 (default code 01-010101) are the only available users. Every time in which the Manager code performs an opening, it resets the code of the user 01 bringing it to its standard code (01-010101). Custom configurations, which can be set through the Pulse PRO setup software, are available since Configuration number 90 to Configuration number 98.
- Page 64 Page 18 of 24 IU_PulsePRO_05...
- Page 65 10 USERS Manager Configuration Manager Configuration Manager Master Manager Master management number management number 10 Users 10 Users in dual mode ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓...
- Page 66 10 USERS + 1 OVERRIDE USER, Dual combination Manager Configuration Manager Configuration Manager Master Manager Master management number management number 10 Users + 1 Override user in dual 10 Users + 1 Override user. All with all users users in dual combination ✓...
- Page 67 50 USERS Manager Configuration Manager Configuration Manager Master Manager Master management number management number 50 Users 50 Users in dual mode ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓...
- Page 68 50 USERS + 10 OVERRIDE USERS, Dual combination Manager Configuration Manager Configuration Manager Master Manager Master management number management number 50 Users + 10 Override users in 50 Users + 10 Override users. dual with all users All users in dual combination ✓...
- Page 70 To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Vlijtstraat 40 • 7005 BN Doetinchem • The Netherlands • www.m-locks.com...
