Initial Inspection/ 初始检查 / 初始檢查
When you open the carton, please make sure that the following materials have been
shipped:

ACP-4D00 Chassis, including one 4U cage and two sub-system chassis

Accessory box:
– Rack-mount Ear x 2 (P/N: 1960061965N000)
– Rack-mount Ear Screw x 4 (P/N: 1931040800)
– Rubber Foot x 4 (P/N: 1990012452S000)
– Rubber Foot Screw x 4 (P/N: 1939000410)
– Power Cord Hook (Type 1) x 2 (P/N: 1960015826T00N)
– Power Cord Hook (Type 2) x 2 (P/N: 1960015825T00N)
– EMI Spring Plate x 2 (P/N: 1960058103T000)
– Rubber Clamp for Add-on Card x 10 (P/N: 1992610020)
– Rubber Clamp for CPU card x 4 (P/N: 1990000980)
– Screw for Fixing the Hard Drive x 12 (P/N: 1930000252)
– Screw for Fixing the Mobile Rack IDT-3120E x 12 (P/N: 1939000361)
– Screw for Fixing Backplane x 8 (P/N: 1930005172)
– Screw for Fixing the PSU x 10 (P/N: 1931060502)
– User Manual (P/N: 20014D0000)
– Warranty card (P/N: 2190000902)
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. We have carefully inspected the product mechanically and
electrically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. As you unpack the product, check it for signs of shipping
damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it
fails to meet the specifications, notify our service department or your local sales rep-
resentative immediately. Also, please notify the carrier. Retain the shipping carton
and packing material for inspection by the carrier. After inspection, we will make
arrangements to repair or replace the unit.
打开包装时，用户需确认包装中含有下面所列各项：
 ACP-4D00 机箱 ( 含 1 个 4U 框体与 2 个子系统机箱 )

附件盒：
耳翼 x 2 (P/N: 1960061965N000)
–
耳翼螺丝 x 4 (P/N: 1931040800)
–
橡胶脚垫 x 4 (P/N: 1990012452S000)
–
橡胶脚垫螺丝 x 4 (P/N: 1939000410)
–
电源线卡钩 ( 样式 1) x 2 (P/N: 1960015826T00N)
–
电源线卡钩 ( 样式 3) x 2 (P/N: 1960015825T00N)
–
背板 EMI 弹片 x 2 (P/N: 1960058103T000)
–
压制外插卡之橡胶垫 x 10 (P/N: 1992610020)
–
压制主板之橡胶垫 x 4 (P/N: 1990000980)
–
硬盘螺丝 x 12 (P/N: 1930000252)
–
IDT-3120 螺丝 x 12 (P/N: 1939000361)
–
背板螺丝 x 8 (P/N: 1930005172)
–
电源螺丝 x 10 (P/N: 1931060502)
–
用户手册 (P/N: 20014D0000)
–
质保卡 (P/N: 2190000902)
–
