Dimension Diagram/ 产品尺寸 / 產品尺寸
1.5
POWER SUPPLY
400.20 [15.76]
389.40 [15.33]
349.40 [13.76]
92.00 [3.62] 92.00 [3.62] 92.00 [3.62]
Figure 1.1 Dimension diagram/ 产品尺寸 / 產品尺寸
101.60 [4.00]
177.00 [6.97]
Unit: mm [inch]
38.30 [1.51]
ACP-4D00 User Manual/ 用户手册
5
37.70 [1.48]
