Expert Power Control NET 8x 8210 / 8211
4.3.5.3
Min. Temperature
Here you can define the minimum temperature, if the sensor measures this temperature the device will generate an alert via
SNMP and Syslog.
4.3.6

Configuration - SNMP

4.3.6.1
SNMP
To get detailed status information of Expert Power Control NET 8x 8210 / 8211 SNMP can be used. SNMP communicates
via UDP (port 161) with Expert Power Control NET 8x 8210 / 8211: You can use SNMP to switch the power ports as well.
Supported SNMP commands:
- SNMPGET:
- SNMPGETNEXT:
- SNMPSET:
You will need a Network Management System, e.g. HP-Open View, OpenNMS, Nagios etc., or the command line tools of
NET-SNMP to request information of Expert Power Control NET 8x 8210 / 8211 via SNMP.
SNMP-communities
4.3.6.1.1
SNMP authentifies requests by so called communities.
The public community has to be added to SNMP-read-requests and the private community to SNMP write requests. You can
see the SNMP communites like read/write passwords. SNMP v1 and v2 transmit the communities without encryption.
Therefore it is simple to spy out these communities. We recommend to use a DMZ or IP ACL.
MIB
4.3.6.1.2
All information, that can be requested or changed, the so called „Managed Objects", are descripted in „Management
Information Bases" (MIBs).
There are three MIBs, which can be requested from Expert Power Control NET 8x 8210 / 8211:
„system", „interface" and „powerports"
„system" and „interface" are standardised MIBs (MIB-II).
„powerports" (GUDEADS-EPC-MIB::gadsEPC) was created especially for Expert Power Control NET 8x 8210 / 8211.
At least, there are so called Object Identifiers (OID) subordinated to those three structures. An OID describes the location of
an information inside a MIB.
SNMP-traps
4.3.6.1.3
SNMP-Traps are system messages, sent via SNMP-protocol to different clients. On following events, Expert Power Control
NET 8x 8210 / 8211 will dispatch a SNMP-Trap:
Switching of the Power Ports
Min/Max-Alerts from the sensors
You can find more information about configuration of SNMP at http://www.gude.info/wiki.
request status information
request the next status information
Expert Power Control NET 8x 8210 / 8211 request change of status
15
