Gira Powernet Switchactuator 2fold Installation Instructions

GIRA Powernet Switchactuator 2fold/4fold
Info
Installation Instructions
Powernet Switchactuator 2fold
Powernet Switchactuator 4fold
230 V AC~
50 Hz
L
N
N N L
1 2 3 A1
µ
4 5 6
A2
230 V AC~
50 Hz
L
N
N N
1 2 3 7 8 9
A1 A3
µ µ
4 5 6 10 11 12
A2 A4
Powernet Switchactuator 2fold/4fold
L
L L

System Information

This device is a product of the GIRA-Powernet ®
EIB system and complies with EIBA directives.
Detailed technical knowledge obtained in instabus or
GIRA-Powernet ® EIB training courses is a pre-
requisite to proper understanding.
The functionality of this device depends upon the
software. Detailed information on loadable software
and attainable functionality may be taken from the
manufacturer's ETS2 product database as well as
from the GIRA-Powernet
Planning, installation and commissioning of the unit
is done by means of the ETS2 software, Ver. 1.1 or
later, as well as by the GIRA-Powernet
troller.

Function

The Switchactuator allows two (or, respectively,
four) groups of loads to be switched independent of
each other.

Connection

Establish electrical connection as shown in the
opposite illustration.
Where:
®
GIRA-Powernet EIB connection.
Programming key.
Programming LED
The connection of different external leads to the
channels is admissible.

Indications of danger

Caution! The installation and assembly of
electrical equipment may be carried out only by
a skilled person. Do not connect any loads/types
of load other than specified.
Subject to change without notice.
03/99
Art. Nr.: 0430 00
Art. Nr.: 0433 00
®
EIB controller database.
®
EIB con-
Page: 1 of 3
