CHAPTER -7: SWITCHING ON THE MACHINE AND SELECTING A
PROGRAMME
Compatibility between options
Options
Half load
-
Half load
Tablet
OK
Start delay
OK
Extra Fast
OK
Extra
OK
Silent
Energy
OK
Save
How to change from "ECO MODE" to "NORMAL MODE" for Inner Light option:
1- Open the dishwasher door and press the Power On/Off touch button. (1) (If it is in OFF position)
2- Press ''Tablet/Energy Save''and "Delayed start".(4) touch buttons simultaneously for 5 seconds.
3- *"IL0" will be shown in the display (3) for 2 seconds to show the "Normal Mode" is selected for inner light option.
4- After "Normal Mode" is selected, the inner light will be ON as long as the machine is energized and machine
door is open.
How to change from "NORMAL MODE" to "ECO MODE" for Inner Light option:
1- Open the dishwasher door and press the Power On/Off touch button.(1) (If it is in OFF position)
2- Press ''Tablet/Energy Save''and "Delayed start" (4) touch buttons simultaneously for 5 seconds.
3- "IL1" will be shown in the display (3) for 2 seconds to show the "Eco Mode" is selected for inner light option. Also
inner light turns OFF and ON again (blinks momentarily) to show this selection is activated.
4- After "Eco Mode" is selected, the inner light will be ON for 4min and then turns OFF. If any user intervention
occurs such as pressing touch buttons, Eco Mode cycle will start from the beginning (inner light is ON for 4min and then
becomes OFF again)
Note: Factory setting for inner light are set to ''IL1''.
(1)
Buzzer sound set up
The buzzer sound level can be adjusted.
1- Press the Power On/Off touch button".(1) (if it is in OFF position).
2- Press the "Tablet/Energy Save" (5) and "½ Half Load Button" (6) touch buttons for 3 seconds at the same
time to set the level.
3- While pressing "Tablet/Energy Save" (5) and "½ Half Load Button"(6) touch buttons (during 3 seconds.),
display shows character of countdowning from 3 to 1.
• If volume adjustment is done the first time, at the end of 3 seconds, "S03" is shown in the display.
• If volume adjustment is done before, At the end of 5 seconds, the last set level is shown on the display (from
''S00'' to ''S03'').
The user can increase or decrease the voice level with ''Tablet'' and "½ Half Load Button".(6) touch buttons. The
characters must be as follows;
- To increase the level of the buzzer sound
1) Press " ½ Half Load Button" touch button. (6)
2) Display (3) changes from "S00" to "S03"
- To decrease the level of the buzzer sound
1) Press "Tablet/Energy Save" touch button. (5)
2) Display (3) changes from "S03" to "S00". "S00" means that all buzzers are off.
4- To exit volume control mode ,switch off the machine.
The last volume level was set is stored in memory.
Note: From sound level ''3'' to ''1'', the loudness level is reduced by stages depending on the sound level.
Tablet
Start delay
OK
-
OK
OK
OK
OK
(2)
(11)
( )
3
Extra Fast
OK
OK
OK
OK
-
OK
-
OK
-
OK
OK
OK
(9)
(4)
(5)
EN-22
Extra Silent
Energy Save
OK
OK
OK
OK
OK
OK
-
OK
-
OK
-
OK
(8)
(6)
( 7)
