1.4 Connection

1
2
1
HDMI IN
2
RGB IN
3
DC12V IN
4
VIDEO-1 IN
5
VIDEO-1 OUT
6
VIDEO-2 OUT
7
VIDEO-2 IN
8
S-VIDEO IN
9
VIDEO AUDIO IN
10
PC AUDIO IN
INSTALLATION
3
4
5
Installation and User's Guide
6
7
8
9
10
pg8
