1.3 Main Functional Button

1 MENU
Activates and exits the OSD.
2 SOURCE / ▽
Select input source, and move the OSD menu.
3
AUTO / △
Move the OSD menu and auto adjustment of RGB source.
4 IR RECEIVER & POWER INDICATOR WINDOW
◁ / VOLUME
5
Decrease the level of volume and move the previous menu.
VOLUME / ▷
6
Increase the level of volume and select the OSD menu.
/
7
Turn the power ON or OFF. There will be a few seconds delay before the display appears.
The power LED(in the power indicator window) lights with green when the power is turned ON.
The power is turned off by pressing the power switch again and the power LED goes Red.
