JSI Flux Installation Instructions

Flux

Attaching Run-off Desk with End Panel to a Support Credenza

Recommended Tools

Product Layout Plan
Screw Gun Phillips Head Bit
Step 1
Attaching the Flat Brackets
• Determine the location (from the plan)for the
run-off desk. Make sure
credenza is level and placed correct in the
layout location.
• Evenly space out a bracket locations provided
with run-off desk. The flat bracket should be
centered half way between the bracket length.
recommended one brackets be
located in front of the standard modesty
panel.
• See diagram A for flat bracket spacing
• Fasten the flat bracket to the credenza using
the provided screws, #8 x
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
Screw Driver Pencil
Level
Drill Bit
Tape Measure
.
"
7
/
8 .
jsifurniture.com 812.482.3204
800.457.4511 812.482.1548

Credenza Type

Hardware Used
Flat Bracket
Diagram A
225 Clay Street / PO Box 231
O
Jasper, Indiana 47546
F
Installation Instructions
#8 x " Wood Screws
7
/
8
four (4) brackets
included
Page 1 of 2
Form No. INST-FL012
1-23-18
