RUN-OFF TABLE AND MEDIA
PANEL ASSEMBLY
Recommended tools
Hardware enclosed
5/16 Flat Washer – 4 per
5/16 Split Lock Washer – 4 per
5/16-18 x 2-1/4 Hex Head Bolt – 4 per
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Run-off table leg pre-assembled. See
run-off table leg install instructions.
UNIT WILL BE MADE FROM 2 MODELS:
• (1) Run-off Table
• (1) Media Panel
STEP 1:
• Grab access media panel access door by the hand
hold
• Firmly pull straight out to disengage the clips
• Set access panel to the side during install
INSTALLATION INSTRUCTIONS
