(5) If user use UART to USB cable, user need to connect the cable to module serial port and the
USB port of the computer, then follow step 1~3.

6.4 Downloading

Connect the USB port line to the USB port, connect the direct current source adapter, run the
download program, and choose the correct image, please follow the QDL downloading menu for
the operation. Update procedure is described in the figure below.
START
Module power on
Connect module USB slot and PC by USB cable
Install module driver on windows OS.
Copy new firmware into QDL data folder
Close all app software which
use USB virtual ports

6.5 Turning off

Press the POWER_ON for about 1 second, SIM5360 module will be turned off.
NOTE: If user uses USB to power on the module, just disconnect the USB cable to turn off.
SIM5360A EVB User Guide
Figure 17: USB interface update procedure
22
Smart Machine Smart Decision
Double click QDL.exe,
update begin
Waiting until download finish,
QDL quit out automatically
Update success
