Choosing a RAID Level

This section provides a brief overview of the RAID levels supported by your Adaptec RAID
controller, including the minimum and maximum number of disk drives required by each.
RAID 0 (Non-redundant Array)—Stripes data across multiple disk drives. Improved
performance but no redundancy (see
RAID 1 Array—Created from two disk drives where one disk drive is a mirror of the other
(the same data is stored on each disk drive). Redundancy, but reduced capacity (see
RAID 1E Array—Similar to a RAID 1 array except that data is mirrored and striped, and more
disk drives can be included (see
RAID 5 Array—Stripes data for improved performance and uses parity data to provide
redundancy (see
RAID 5EE Array—Similar to a RAID 5 array, but includes a distributed spare and must
include a minimum of four disk drives (see
RAID 10 Array—Built from two or more equal-sized RAID 1 arrays, stripes and mirrors
data across multiple disk drives. Redundancy and improved performance (see
1
RAID 50
arrays, stripes stored data and parity data across all disk drives (see
RAID 6 Array—Similar to a RAID 5 array except that it includes two independent sets of
parity data instead of one (see
1
RAID 60 Array—Similar to a RAID 50 array except that it includes four independent sets
of parity data instead of two (see
Use the table on
controller to support the RAID level you want.
1
The Adaptec 2420SA RAID controller can support RAID 50 or RAID 60 only when expanders are used to connect more
than four disk drives.
page 71).
page 73).
Array—Built from multiple disk drives configured as two or more RAID 5
page 76).
page
page 77 to see how many disk drives you must connect to your RAID
Chapter 4: Getting Started
page 70).
page 74).
76).
26
page 71).
page 72).
page 75).
