Summary of Contents for Adaptec 4000SAS

  • Page 1 SAS, SATA, and SCSI RAID Controllers Installation and User’s Guide...
  • Page 2 Copyright ©2005 Adaptec, Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
  • Page 3 Adaptec Customer Support If you have questions about installing or using your Adaptec product, check this document first—you will find answers to most of your questions. If you need further assistance, use the support options listed below. To expedite your service, have your computer in front of you.
  • Page 4 Limited 3-Year Hardware Warranty 1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from defects in material and workmanship for a period of three (3) years from the date of purchase. If the product should become defective within the warranty period, Adaptec, at its option, will repair or replace the product, or refund the purchaser’s...
  • Page 5: Regulatory Compliance Statements

    This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Adaptec, Inc. ASR-4000SAS/ASR-4800SAS/ASR-4805SAS AAR-2420SA/AAR-2820SA ASR-2130SLP/ASR-2230SLP...
  • Page 6 Canadian Compliance Statement This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Japanese Compliance (Voluntary Control Council Initiative) This equipment complies to class B Information Technology equipment based on VCCI (Voluntary Control Council for Interface).
  • Page 7: Table Of Contents

    Using a Feature Key to Unlock Enhanced Features ....21 Adding a Battery Backup Module..........21 Upgrading the Controller Firmware..........21 About the Adaptec 4000SAS ............22 About the Adaptec 4800SAS ............23 About the Adaptec 4805SAS ............24 About the Adaptec 2420SA ............25 About the Adaptec 2820SA ............
  • Page 8: Contents

    Setting the Boot Controller ............44 Creating an Array ................44 Creating an Array with the ACU ........... 45 Creating an Array with Adaptec Storage Manager ....47 Making Your Array Bootable............49 Installing the Driver and an Operating System Before You Begin ................
  • Page 9 Managing Your Storage Space About Adaptec Storage Manager ..........61 Installing Adaptec Storage Manager ........61 About the Adaptec RAID Controller Configuration Utility ..62 About the Adaptec RAID Controller Utility ........ 62 About the Adaptec Flash Utility............ 63 Which Utility Should I Use?............63 10 Solving Problems Troubleshooting Checklist ............
  • Page 10 RAID 60 Arrays................88 Selecting the Best RAID Level ............89 Using the Adaptec RAID Controller Utility Introduction to the Adaptec RAID Controller Utility....91 Running the Adaptec RAID Controller Utility......91 Navigating the Adaptec RAID Controller Utility....91 Using the ACU to Create and Manage Arrays ......92 Creating a New Array .............
  • Page 11 Array Definition Block Keywords........105 Channel Definition Block Keywords—SCSI only....111 ACU Error Codes..............112 Sample Scripts ............... 113 Using the Adaptec Flash Utility System Requirements ..............116 Before You Begin ................. 116 Obtaining the Firmware ............116 Creating the Firmware Floppy Disks ........117 Running the Menu-based AFU...........
  • Page 12 Terminology Used in this Guide ............13 How to Find More Information............14 ® This Installation and User’s Guide explains how to install your Adaptec RAID controller. It also describes the utilities included in your controller kit, and provides a basic overview of Serial Attached SCSI (SAS) technology.
  • Page 13: About This Guide

    Terminology Used in this Guide Because you can use your Adaptec RAID controller to manage data storage in a variety of configurations from DAS to SAN, the generic term “storage space” is used to refer to controller(s) and disk drives...
  • Page 14: How To Find More Information

    Chapter 1: About This Guide How to Find More Information You can find more information about your Adaptec RAID controller and the software and utilities included with it by referring to these documents: Readme.txt—Includes updated product information and known issues; located on the RAID Installation CD.
  • Page 15 System Requirements In this chapter... Kit Contents ..................16 System Requirements................. 17 This chapter lists the contents of your Adaptec RAID controller kit and the system requirements that must be met for you to successfully install and use your controller.
  • Page 16: Kit Contents And System Requirements

    RAID Installation CD (bootable), including controller drivers, and this Guide Adaptec Storage Manager Installation CD (not bootable), including user guides for Adaptec Storage Manager and the Adaptec RAID controller configuration command line utility (ARCCONF) Cables (type and quantity vary—for cable information about your...
  • Page 17: System Requirements

    Windows 2000, Windows Server 2003, Windows XP ® Red Hat Linux SuSE Linux Note: For the latest on Adaptec’s support of Linux, or to download driver sources, visit the Support area of the Adaptec Web site at www.adaptec.com ® ®...
  • Page 18 About the Adaptec 2130SLP.............. 27 About the Adaptec 2230SLP.............. 28 This chapter provides an overview of standard Adaptec RAID controller features, and describes the unique features of your controller. It also explains how to upgrade your controller with enhanced features.
  • Page 19: About Your Raid Controller

    Some RAID controllers support a battery backup module (see page 21). Array-level Features Note: For more information, refer to the Adaptec Storage Manager User’s Guide or online Help. Support for RAID 0, RAID 1, RAID 5, RAID 10, RAID 50 , simple...
  • Page 20: Adding Enhanced Features

    For more information about RAID levels, see Understanding RAID on page To purchase a feature key, contact your Adaptec Reseller or refer to the Adaptec Web site at . To unlock the enhanced features www.adaptec.com...
  • Page 21: Using A Feature Key To Unlock Enhanced Features

    Adaptec Battery Module 500 Adaptec 2130SLP / Adaptec 2230SLP Adaptec Battery Module 400 To purchase a backup battery module, refer to the Adaptec Web site at www.adaptec.com Upgrading the Controller Firmware To upgrade the firmware on your Adaptec RAID controller, follow the...
  • Page 22: About The Adaptec 4000Sas

    Chapter 3: About Your RAID Controller About the Adaptec 4000SAS The Adaptec 4000SAS is a low-profile SAS Zero Channel RAID controller with these features: LED connector Mode 0 Flash connector I2C connector PCI-X connector Mounting bracket Bus compatibility PCI-X Maximum bus width...
  • Page 23: About The Adaptec 4800Sas

    Chapter 3: About Your RAID Controller About the Adaptec 4800SAS The Adaptec 4800SAS is a SAS RAID controller with these features: Mode 0 Flash connector Alarm connector Two 4-wide internal SAS connectors Mounting bracket One external connector Battery connector Activity LED connector...
  • Page 24: About The Adaptec 4805Sas

    Chapter 3: About Your RAID Controller About the Adaptec 4805SAS The Adaptec 4805SAS is a SAS RAID controller with these features: Mode 0 Flash connector Alarm connector Two 4-wide internal SAS connectors Mounting bracket One external connector Battery connector Activity LED connector...
  • Page 25: About The Adaptec 2420Sa

    Chapter 3: About Your RAID Controller About the Adaptec 2420SA The Adaptec 2420SA is a SATA RAID controller with these features: SATA ports Mode 0 Flash connector Activity LED connector I2C connector Battery connector PCI-X connector Mounting bracket Bus compatibility PCI-X, 3.3 V...
  • Page 26: About The Adaptec 2820Sa

    Chapter 3: About Your RAID Controller About the Adaptec 2820SA The Adaptec 2820SA is a SATA RAID controller with these features: SATA ports Mode 0 Flash connector Activity LED connectors I2C connector Battery connector PCI-X connector Mounting bracket Bus compatibility PCI-X, 3.3 V...
  • Page 27: About The Adaptec 2130Slp

    Chapter 3: About Your RAID Controller About the Adaptec 2130SLP The Adaptec 2130SLP is a low-profile controller with these features: Activity LED Mode 0 Flash connector connector Battery Internal HD SCSI connector connector Mounting bracket External VHDCI SCSI connector PCI/PCI-X connector Bus compatibility PCI / PCI-X, 3.3 V...
  • Page 28: About The Adaptec 2230Slp

    Chapter 3: About Your RAID Controller About the Adaptec 2230SLP The Adaptec 2230SLP is a low-profile controller with these features: Activity LED connector Mode 0 Flash connector Battery connector 2 internal HD SCSI connectors 2 external VHDCI SCSI connectors PCI/PCI-X connector...
  • Page 29: Getting Started

    This chapter provides the basic information you need to set up your disk drives and arrays the way you want them. It also describes the options you have for installing your Adaptec controller and disk drives, and creating arrays for data storage.
  • Page 30: Choosing A Raid Level

    89 to see how many disk drives you must connect to your RAID controller to support the RAID level you want. Because it supports four disk drives only, the Adaptec 2420SA RAID controller can’t support RAID 50 or RAID 60.
  • Page 31: Selecting Disk Drives

    You can use different-sized disk drives in the array, but the array will be limited to the capacity of the smallest and slowest disk drive. For more information, refer to the Adaptec Storage Manager User’s Guide or online Help. Disk Drives for SAS Controllers Your SAS controller supports both SAS and SATA disk drives.
  • Page 32: Selecting Cables

    External cable—Connects to an external SAS enclosure. Cable connectors are keyed so that you can’t insert them incorrectly. Adaptec recommends using only Adaptec SAS cables. For more information or to purchase cables, visit the Adaptec Web site at www.adaptec.com...
  • Page 33: Sata Cables

    SATA Cables You need one SATA cable for each disk drive you are connecting to your Adaptec SATA RAID controller. SATA cables are included in the kit. All SATA cables have the same connectors, as shown in the figure below, and the connectors are keyed so that you can’t insert them incorrectly.
  • Page 34: Installation Options

    Chapter 4: Getting Started Installation Options When you install your Adaptec controller, you can choose to create a bootable array and then install your operating system and the controller driver on that array. Alternatively, you can complete a standard installation, where the controller driver is installed on an existing operating system.
  • Page 35 Connecting Disk Drives to SATA RAID Controllers......41 Connecting Disk Drives to SCSI RAID Controllers......41 Connecting External Devices ............42 This chapter explains how to install your Adaptec RAID controller, and how to install and connect internal and external disk drives.
  • Page 36: Installing The Controller And Disk Drives

    Caution: Handle the controller by its bracket or edges only. Installing the Controller This section describes how to install your Adaptec RAID controller into your computer cabinet. Turn off your computer and disconnect the power cord. Open the cabinet, following the manufacturer’s instructions.
  • Page 37 Ensure that the positive lead of the LED cable (usually a red wire or a wire marked with a red stripe) is attached to pin 1. Note: Adaptec 4000SAS only—Controller installation is complete. If you are installing the controller driver and an operating system on a...
  • Page 38: Connecting Disk Drives To Sas Raid Controllers

    30 for more information. Note: Although you can connect both SAS and SATA disk drives to your SAS controller, Adaptec recommends that you not combine SAS and SATA disk drives within the same array or logical drive. See page 71 more information.
  • Page 39: Connecting Directly To The Controller

    Chapter 5: Installing the Controller and Disk Drives Connecting Directly to the Controller In a direct-attach connection, SAS or SATA disk drives are connected directly to a SAS card with SAS cables.The number of direct-attached disk drives is limited to four per internal SAS connector. (For more information about direct-attach connections, see page 75.)
  • Page 40: Connecting To A System Backplane

    Chapter 5: Installing the Controller and Disk Drives Connecting to a System Backplane In a backplane connection, disk drives and SAS cards are attached to and communicate with each other through a system backplane. The number of disk drives is limited to the number of slots available on the backplane.
  • Page 41: Connecting Disk Drives To Sata Raid Controllers

    For each controller channel, set the SCSI ID of each disk drive to a unique number between 0 and 15. The controller is set to ID 7 by default. Although not recommended, you can change the controller ID by using the Adaptec RAID Controller utility (see page 90).
  • Page 42: Connecting External Devices

    Use high-quality cables to connect your controller to your external device(s), such as disk drives or disk drive enclosures. Adaptec recommends using only Adaptec cables. For more information or to purchase cables, visit the Adaptec Web site at www.adaptec.com Next Steps...
  • Page 43 Creating an Array................44 Making Your Array Bootable............. 49 This chapter explains how to set your Adaptec controller to be the boot controller, and how to create a bootable array. Note: If you are completing a standard installation onto an existing operating system, you don’t have to complete this task.
  • Page 44: Creating A Bootable Array

    (see page 61). You can use either tool, but the Adaptec RAID Controller utility is the quicker and easier tool for this task. Note: Adaptec recommends that you not combine SAS and SATA disk drives within the same array. Adaptec Storage Manager generates a warning if you try to create a logical drive using a combination of SAS and SATA disk drives.
  • Page 45: Creating An Array With The Acu

    Caution: During initialization, all data is deleted from the disk. Before continuing, back up any data you want to keep. Press Y, then press Enter. The selected disk drives are initialized, then the Adaptec Configuration Utility screen appears. Select Create Array, then press Enter.
  • Page 46 Chapter 6: Creating a Bootable Array When the Array Properties screen opens, follow the instructions in the table below: Property Line Entry or Selection Array Type Select RAID 5, then press Enter. Array Label Type a name, then press Enter. Array Size Press Enter, then press Enter again to use the default granularity of GB.
  • Page 47: Creating An Array With Adaptec Storage Manager

    Chapter 6: Creating a Bootable Array Creating an Array with Adaptec Storage Manager This section describes how to use the Adaptec Storage Manager configuration wizard to build a RAID 5 array. Note: You will need the RAID Installation CD to complete this task.
  • Page 48 Click Apply, then click Yes when prompted to confirm applying your new configuration. Adaptec Storage Manager builds the logical drive(s). The configuration is saved on the Adaptec controller (as an “array”, page 13) and on the physical disk drives. Partition and format your logical drive.
  • Page 49: Making Your Array Bootable

    Chapter 6: Creating a Bootable Array Making Your Array Bootable Use the ACU to make the array bootable (see Creating Bootable Arrays on page 93). Then continue with Installing the Driver and an Operating System on page...
  • Page 50 Installing the Driver and an Operating System In this chapter... Before You Begin................51 Creating a Driver Disk............... 51 Installing with Windows..............52 Installing with Red Hat Linux ............53 Installing with SuSE Linux ..............53 Installing with NetWare..............54 This chapter explains how to install your ICP RAID controller driver and an operating system onto a bootable array (see page...
  • Page 51: Installing The Driver And An Operating System

    Chapter 7: Installing the Driver and an Operating System Before You Begin Install and connect your ICP RAID controller and internal disk drives (see page 35). Create a bootable array (see page 43). Create a driver disk (see below). Creating a Driver Disk Note: You will need a floppy disk to complete this task.
  • Page 52: Installing With Windows

    Chapter 7: Installing the Driver and an Operating System Continue with the instructions for your operating system: For Windows, see below. For Red Hat Linux, see page For SuSE Linux, see page For NetWare, see page Installing with Windows Note: You will need your Windows installation CD to complete this task.
  • Page 53: Installing With Red Hat Linux

    Chapter 7: Installing the Driver and an Operating System Installing with Red Hat Linux Note: You will need your Red Hat installation CD to complete this task. To install the ICP RAID controller driver while installing Red Hat Linux: Insert the first Red Hat installation CD. Restart your computer.
  • Page 54: Installing With Netware

    Chapter 7: Installing the Driver and an Operating System Complete the Linux installation, following the instructions included with your operating system. Continue with Managing Your Storage Space on page Installing with NetWare Note: You will need your NetWare installation CD to complete this task.
  • Page 55 Chapter 7: Installing the Driver and an Operating System From the lower window menu, select Continue, then press Enter. If the driver installation process fails, the server console is displayed so you can see the cause of the failure. To modify disk partitions, apply hot fixes, or perform volume maintenance, refer to your NetWare documentation.
  • Page 56 Installing on Windows............... 58 Installing on Red Hat or SuSE Linux ..........58 Installing on NetWare................ 59 This chapter explains how to install your Adaptec RAID controller driver. Note: To install the driver while you’re installing an operating system, see...
  • Page 57: Installing The Driver On An Existing Operating System

    Turn on your computer, then insert the RAID Installation CD included in your RAID controller kit. Follow the on-screen instructions to get to the Adaptec Start Menu. Click Create Driver Disk, then select your operating system. Linux only—Select your operating system and the architecture: Intel 386 or 486 computers—Select i386.
  • Page 58: Installing On Windows

    Chapter 8: Installing the Driver on an Existing Operating System Installing on Windows To install the driver on Windows: Start or restart Windows. The Found New Hardware Wizard opens and searches for the driver. Insert the driver disk, select Floppy drive, then click Next. Click Next, then click Next again.
  • Page 59: Installing On Netware

    Chapter 8: Installing the Driver on an Existing Operating System Installing on NetWare Note: Before you begin, ensure that your NetWare OS has been upgraded to the minimum patch level specified by Novell. Refer to the Novell Web site for more information. To install the driver on NetWare: Start your computer.
  • Page 60 About the Adaptec RAID Controller Utility ........62 About the Adaptec Flash Utility............63 Which Utility Should I Use? .............. 63 Once you have installed your Adaptec RAID controller, disk drives (or other devices), and device driver, you can begin to build and manage your storage space.
  • Page 61: Managing Your Storage Space

    About Adaptec Storage Manager Adaptec Storage Manager is a full-featured software application that helps you build a storage space for your online data, using Adaptec RAID controllers and disk drives. With Adaptec Storage Manager, you can group disk drives into logical drives and build in redundancy to protect your data and improve system performance.
  • Page 62: About The Adaptec Raid Controller Configuration Utility

    Recover from disk drive failures and troubleshoot ARCCONF and the Command Line Interface (CLI) User’s Reference, which describes how to use ARCCONF, are included on the Adaptec Storage Manager Installation CD. Note: Adaptec recommends that only advanced users familiar with command line interfaces use ARCCONF.
  • Page 63: About The Adaptec Flash Utility

    Chapter 9: Managing Your Storage Space About the Adaptec Flash Utility The Adaptec Flash Utility (AFU) is a text-based DOS utility that you can use to update, save, or verify your RAID controller’s firmware BIOS and Non-Volatile Random Access Memory (NVRAM).
  • Page 64: Solving Problems

    Solving Problems In this chapter... Troubleshooting Checklist..............65 Silencing the Alarm................66 Recovering from a Disk Drive Failure..........66 Resetting the Controller ..............68 This chapter provides basic troubleshooting information and solutions for solving controller problems.
  • Page 65: Troubleshooting Checklist

    Ensure that your Adaptec RAID controller firmly seated and secured in the PCI/PCI-X/PCI-E expansion slot. If your Adaptec RAID controller is not detected during system boot, try installing it in a different compatible expansion slot. (See page 36 for instructions.) SCSI RAID controllers only—Ensure that each SCSI disk drive (or...
  • Page 66: Silencing The Alarm

    Chapter 10: Solving Problems Silencing the Alarm If your Adaptec RAID controller includes an alarm, the alarm will sound when an error occurs. To silence the alarm, use Adaptec Storage Manager (see Managing Your Storage Space on page 60.) Recovering from a Disk Drive Failure...
  • Page 67: Failed Disk Drive Not Protected By A Hot Spare

    If the controller fails to rebuild the array, check that the cables, disk drives, and controllers are properly installed and connected. Then, if necessary, use Adaptec Storage Manager to rebuild the array. For instructions, refer to the Adaptec Storage Manager User’s Guide or online Help. Failure in Multiple Arrays Simultaneously If there’s a disk drive failure in more than one array at the same time...
  • Page 68: Multiple Failures In The Same Array

    (if available). Note: In some instances, RAID 10 and RAID 50 arrays may survive multiple disk drive failures, depending on which disk drives fail. For more information, refer to the Adaptec Storage Manager User’s Guide or online Help. Resetting the Controller This section explains how to reset (or flash) your Adaptec RAID controller.
  • Page 69 Chapter 10: Solving Problems At the prompt, type a: AFU UPDATE CONTROLLER where x is the controller number. Insert the other floppy disks when prompted. When the flash is complete, power off your computer, disconnect the power cord, then remove the jumper. Close the computer cabinet, reconnect the power cord, then power on your computer.
  • Page 70 Introduction to Serial Attached SCSI (SAS) In this appendix... Terminology Used in This Chapter........... 71 What is SAS?..................71 How Do SAS Devices Communicate?..........72 What’s a Phy?..................72 What’s a SAS Port? ................73 What’s a SAS Address? ............... 73 What’s a SAS Connector? ..............74 What do SAS Cables Look Like? ............
  • Page 71: Terminology Used In This Chapter

    Note: Although you can use both SAS and SATA disk drives in the same SAS domain (see page 77), Adaptec recommends that you not combine SAS and SATA disk drives within the same array or logical drive. The difference in performance between the two types of disk drives may adversely affect the performance of the array.
  • Page 72: How Do Sas Devices Communicate

    Appendix A: Introduction to Serial Attached SCSI (SAS) How Do SAS Devices Communicate? SAS devices communicate with each other through links. A link is a physical connection between two phys. As shown below, SAS devices contain ports (see page 73), ports contain phys (see below), and each phy contains one transmitter and one receiver—one transceiver.
  • Page 73: What's A Sas Port

    Appendix A: Introduction to Serial Attached SCSI (SAS) What’s a SAS Port? Note: Because the physical link between SAS devices is from phy to phy, rather than port to port, a “port” is more of a virtual concept, different from what is normally considered a port on other types of RAID controllers and storage devices.
  • Page 74: What's A Sas Connector

    Appendix A: Introduction to Serial Attached SCSI (SAS) What’s a SAS Connector? A SAS connector is the physical plug or receptacle that you see on a SAS device. It supports the power and signal line cable. It’s what you plug a SAS cable into, or the end of the SAS cable that’s being plugged in.
  • Page 75: What Do Sas Cables Look Like

    Appendix A: Introduction to Serial Attached SCSI (SAS) What do SAS Cables Look Like? Internal SAS cables are narrower than internal parallel SCSI cables. The connectors vary in size depending on the number of links they support, from single link connectors to 4-wide (or larger) connectors. Internal fan-out cables (shown below) let you attach four disk drives to a single 4-wide connector.
  • Page 76: What Are The Sas Connection Options

    12 SAS or SATA disk drives. Some backplanes support daisy-chain expansion to other backplanes. For example, you can daisy-chain (connect one to the next) up to nine Adaptec S50 enclosures to a single SAS card in a host system.
  • Page 77: Sas Expander Connections

    Appendix A: Introduction to Serial Attached SCSI (SAS) SAS Expander Connections A SAS expander device literally expands the number of end devices that you can connect together. Expander devices, typically embedded into a system backplane (see page 76), support large configurations of SAS end devices, including SAS cards and SAS and SATA disk drives.
  • Page 78: How Is Sas Different From Parallel Scsi

    Appendix A: Introduction to Serial Attached SCSI (SAS) How is SAS Different from Parallel SCSI? In summary, although SAS and parallel SCSI both use the SCSI command set, how they move data from one place to another is very different. To support point-to-point serial data transport, SAS introduces new types of connectors, cables, connection options, and terminology.
  • Page 79 RAID levels also vary by the number of disk drives they support. This appendix describes the RAID levels supported by your Adaptec RAID controller, and provides a basic overview of each to help you select the best level of protection for your data storage.
  • Page 80: Understanding Drive Segments

    Appendix B: Understanding RAID Understanding Drive Segments A drive segment is a disk drive or portion of a disk drive that is used to create an array. A disk drive can include both RAID segments (segments that are part of an array) and available segments. Each segment can be part of only one logical device at a time.
  • Page 81: Raid 1 Arrays

    Appendix B: Understanding RAID RAID 1 Arrays A RAID 1 array is built from two disk drives, where one disk drive is a mirror of the other (the same data is stored on each disk drive). Compared to independent disk drives, RAID 1 arrays provide improved performance, with twice the read rate and an equal write rate of single disks.
  • Page 82: Raid 1 Enhanced Arrays

    Appendix B: Understanding RAID RAID 1 Enhanced Arrays Note: RAID 1E is an upgrade feature; if the RAID 1E feature is locked, Adding Enhanced Features on page 20 for information on purchasing a feature key. A RAID 1 Enhanced (RAID 1E) array is similar to a RAID 1 array except that data is both mirrored and striped, and more disk drives can be included.
  • Page 83: Raid 10 Arrays

    RAID 10 Arrays A RAID 10 array is built from two or more equal-sized RAID 1 arrays. Adaptec RAID controllers support a maximum number of 48 disk drives in a RAID 10 array. Data in a RAID 10 array is both striped and mirrored. Mirroring provides data protection, and striping improves performance.
  • Page 84: Raid 5 Arrays

    Appendix B: Understanding RAID RAID 5 Arrays A RAID 5 array is built from a minimum of three and a maximum of sixteen disk drives, and uses data striping and parity (see below) data to provide redundancy. Parity data provides data protection, and striping improves performance.
  • Page 85: Raid 5Ee Arrays

    Appendix B: Understanding RAID RAID 5EE Arrays Note: RAID 5EE is an upgrade feature; if the RAID 5EE feature is locked, see Adding Enhanced Features on page 20 for information on purchasing a feature key. A RAID 5EE array is similar to a RAID 5 array except that it includes a distributed spare drive (see below) and must be built from a minimum of four disk drives.
  • Page 86: Raid 50 Arrays

    RAID 5 arrays. (For more information, see RAID 5 Arrays on page 84.) Note: Because the Adaptec 2420SA RAID controller can’t support more than four disk drives, it can’t support RAID 50 arrays. The parity data provides data protection, and striping improves performance.
  • Page 87: Raid 6 Arrays

    Appendix B: Understanding RAID RAID 6 Arrays Note: RAID 6 is an upgrade feature; if the RAID 6 feature is locked, see Adding Enhanced Features on page 20 for information on purchasing a feature key. A RAID 6 array is similar to a RAID 5 array because it uses data striping and parity data to provide redundancy.
  • Page 88: Raid 60 Arrays

    RAID 6 arrays. Note: Because the Adaptec 2420SA RAID controller can’t support more than four disk drives, it can’t support RAID 60 arrays. Two sets of parity data provide enhanced data protection, and striping improves performance.
  • Page 89: Selecting The Best Raid Level

    RAID 60 Because it supports a maximum of four disk drives, the Adaptec 2420SA RAID controller can’t support RAID 50 or RAID 60. Disk drive usage, read performance, and write performance depend on the number of drives in the logical drive. In...
  • Page 90 Using the -Select Utility to Modify Controller Settings....95 Formatting and Verifying Disk Drives..........99 Viewing the Event Log ..............100 The Adaptec RAID Controller utility is a BIOS-based utility that you can use to create and manage controllers, disk drives and other devices, and arrays.
  • Page 91: Introduction To The Adaptec Raid Controller Utility

    99). Running the Adaptec RAID Controller Utility If your Adaptec controller is connected to a RAID enclosure, power on your enclosure (or enclosures) before you power on your computer. Start or restart your computer. When prompted, press Ctrl+A. Note: The first time you power on your computer after you install a new controller, the BIOS may display a configuration that doesn’t...
  • Page 92: Using The Acu To Create And Manage Arrays

    Appendix C: Using the Adaptec RAID Controller Utility Using the ACU to Create and Manage Arrays To open the ACU, start the Adaptec RAID Controller utility (see page 91). If you have more than one controller, select your controller, then press Enter.
  • Page 93: Initializing Disk Drives

    Appendix C: Using the Adaptec RAID Controller Utility Creating Bootable Arrays Note: You may need to change the system BIOS to modify the boot order. For more information, refer to your computer’s documentation. The controller always uses the lowest numbered array as its bootable array.
  • Page 94: Secure Erasing Disk Drives

    (see page 99) instead, or clear it using Adaptec Storage Manager—both options take much less time than the secure erase option. To begin a secure erase, select Secure Erase from the main ACU menu.
  • Page 95: Using The -Select Utility To Modify Controller Settings

    Using the -Select Utility to Modify Controller Settings Included in the Adaptec RAID Controller utility is a tool for modifying the settings of your controller and the disk drives connected to it. This utility is called SASSelect, SATASelect, or SCSISelect, depending on what type of controller you have.
  • Page 96: General Controller Settings

    Appendix C: Using the Adaptec RAID Controller Utility General Controller Settings Note: Default settings are shown in bold type. Option Description Drive’s Write When enabled, write cache is enabled on the disk drive. Cache When disabled, write cache is not used on the disk drive.
  • Page 97: Sas-Specific Controller Settings

    Appendix C: Using the Adaptec RAID Controller Utility SAS-specific Controller Settings In addition to the general settings listed on page 96, your Adaptec SAS controller has SAS-specific settings that can be modified if required. (For more information about SAS, see page 70.)
  • Page 98: Scsi-Specific Controller Settings

    Appendix C: Using the Adaptec RAID Controller Utility SCSI-specific Controller Settings In addition to the general settings listed on page 96, your Adaptec SCSI controller has SCSI-specific settings that can be modified if required. To modify SCSI-specific settings, select SCSI Configuration from the SCSISelect main menu.
  • Page 99: Formatting And Verifying Disk Drives

    Appendix C: Using the Adaptec RAID Controller Utility For the best device performance, don’t change the default settings. Note: Default settings are shown in bold type. Option Description Maximum Shows the maximum data transfer rate that the SCSI Transfer Rate channel supports.
  • Page 100: Viewing The Event Log

    To view the event log: Start the Adaptec RAID Controller utility (see page 91). Select the controller you want, press Enter. When the Adaptec RAID Controller utility menu appears, press Ctrl+P. Select Controller Log Information, then press Enter. The current event log opens.
  • Page 101: Using The Acu For Dos

    (A BIOS-based ACU is also available. See page 92.) Note: Adaptec recommends that only advanced users familiar with working in DOS use the ACU for DOS utility. For more information, Managing Your Storage Space on page...
  • Page 102: Getting Started

    Note: You need a bootable floppy disk to complete this task. The ACU for DOS runs from a floppy disk which you can create using the RAID Installation CD that came in your Adaptec RAID controller kit. To create the ACU floppy disk:...
  • Page 103: Running The Acu Using Scripts

    Appendix D: Using the ACU for DOS Running the ACU Using Scripts To work in the ACU using scripts: Insert the ACU floppy disk (see page 102), then start or restart your computer. The computer boots to the DOS command line. Type on the command line, specify a script file, and specify either the /P or /R switches listed in the table below.
  • Page 104: About Playback Mode

    Appendix D: Using the ACU for DOS About Playback Mode In this mode, the ACU reads the contents of the specified script file and creates arrays based on the keywords specified in the script. The syntax is where is the name of the script file. The ACU /P <file>...
  • Page 105: Creating The Script File Manually

    Appendix D: Using the ACU for DOS Creating the Script File Manually Script files contain blocks: Array definition block keywords (see below) Optional—ACU error codes (see page 112) The syntax rules are: Each keyword must start its own line. Syntax is not case sensitive. Entering Comments in the Script File To enter a comment in the script file, start with a pound character ( You can start anywhere on a line.
  • Page 106 Appendix D: Using the ACU for DOS Keyword Required? Description Size Specifies the size of the array. Default is Maximum. See page 109. StripeSize Specifies the size of contiguous I/O, in bytes. Default is 256. See page 109. Type Indicates the type of array to create. No default See page 109.
  • Page 107 Appendix D: Using the ACU for DOS End Keyword is a required keyword, indicating the end of the block. HotspareDrives Keyword is an optional keyword, specifying the hot spares to HotspareDrives assign to the array. The syntax for listing hot spares is the same as the Drives Keyword on page 106.
  • Page 108 Appendix D: Using the ACU for DOS is a global keyword that you need to specify only once. InitializeAll is always performed prior to array creation regardless of its InitializeAll position in the script. If both are specified in the same script InitializeAll=Yes InitializeAll=No file,...
  • Page 109 Appendix D: Using the ACU for DOS Size Keyword keyword specifies the size of the array. Specify (the Size Maximum default) to create an array using the maximum available space, based on the array type and drives selected. Otherwise, specify the size as an integer or a decimal number, followed by the unit keyword MB (megabytes), GB (gigabytes), or TB (terabytes).
  • Page 110 Appendix D: Using the ACU for DOS Wait Keyword is an optional keyword that you can use to tell the ACU to allow the Wait ACU to continue while the Build/Verify or Clear completes in the background; specify . Otherwise, the ACU waits by default. Wait=No If the host is powered off before the Build/Verify or Clear process completes and is then restarted, the process resumes without any user...
  • Page 111: Channel Definition Block Keywords-Scsi Only

    Normally, the SCSI controller is assigned SCSI ID 7 on each of its channels. You can specify any ID value between 0 and 7. Caution: Do not change the SCSI ID of the controller unless directed to do so by Adaptec Technical Support. For example: ControllerID=7 End Keyword is a required keyword, indicating the end of the block.
  • Page 112: Acu Error Codes

    Appendix D: Using the ACU for DOS ACU Error Codes When the ACU detects an error, it reports the error and exits immediately. If a log file is specified, the ACU writes the error code to the log file. Otherwise, it displays the error code on the screen. The possible error messages returned by the ACU are listed in this table.
  • Page 113: Sample Scripts

    Appendix D: Using the ACU for DOS Sample Scripts The MS-DOS command below invokes the ACU and creates arrays on controller 1 based on the array keywords defined in the script file . It also configures Channel 0 and saves a log of the A:\RAID.ACU operation in the log file C:\RAID.LOG...
  • Page 114 This is a sample ACU file that will initialize all disk drives connected to the SATA controller and create a RAID 5 array with the disk drives on ports 0, 1, and 2. Controller= 0,5:7:0 Controller Name Adaptec 2820SA =Adaptec Subsystem ID=0x2A1 Firmware Version=V5.1-0[6792] Total Ports=8 Port 0 = 0:0:0 Maxtor 279.479GB 279.395GB...
  • Page 115: Using The Adaptec Flash Utility

    Running the AFU from the Command Line ........119 Updating the Flash Using the AFU Command Line...... 123 This chapter describes how to use the Adaptec Flash Utility (AFU), a text-based DOS utility that you can use to update, save, or verify the RAID controller’s firmware BIOS and Non-Volatile Random Access...
  • Page 116: System Requirements

    The RAID Installation CD—Includes the AFU executable ( AFU.exe and a separate flash image. The flash image may comprise multiple User Flash Image (UFI) files. The Adaptec Web site—Download a new firmware file to get the most recent version of AFU. for more information. www.adaptec.com...
  • Page 117: Creating The Firmware Floppy Disks

    At the DOS command prompt, type with no arguments. The AFU’s main menu is displayed. Select Select Controllers, then select the Adaptec RAID controller(s) to be flashed. To update multiple RAID controllers in the same system, update the boot controller’s flash first, restart the computer, then update the...
  • Page 118 Appendix E: Using the Adaptec Flash Utility Select Select an Operation. Choose the operation you want, then follow the on-screen instructions to complete the task: Update—Updates all the flash components on a RAID controller with the flash image data from the UFI file.
  • Page 119: Running The Afu From The Command Line

    Appendix E: Using the Adaptec Flash Utility Running the AFU from the Command Line Note: You can also run a menu-based AFU (see page 117). To run the AFU from the command line: Power off your computer, insert the first AFU floppy disk, then power on your computer.
  • Page 120 Appendix E: Using the Adaptec Flash Utility Save Saves the contents of a RAID controller’s flash in a UFI file. The name of the UFI file is based on the controller type and can’t be changed. You must restart the computer following a SAVE command.
  • Page 121 Appendix E: Using the Adaptec Flash Utility Update Updates the flash components of one or more RAID controllers on your computer from the flash image data in a UFI file. You must restart the computer following an update command. The command syntax for the update command is: UPDATE [/C<Controller ID>] [/D <UFI File Path>]...
  • Page 122 A:\> AFU VERSION /C 0 Adaptec Flash Utility V4.0-0 B5749 (c)Adaptec Inc. 1999–2005. All Rights Reserved. Version Information for Controller #0 (Adaptec Adaptec 2820SA) ROM: Build 5748 [VALID] Fri Sep 27 13:28:40 EDT 2005 A:\> AFU VERSION /C ALL Help Displays a summary of AFU functions and command switches.
  • Page 123: Updating The Flash Using The Afu Command Line

    <cont_number_a>,<cont_number_b> Where are the <controller_number_a> <controller_number_b> numbers of the Adaptec RAID controllers whose firmware you are updating. For example, to upgrade controllers 0, 2, and 3, type AFU UPDATE /C 0, 2, 3 To update all RAID controllers simultaneously: AFU UPDATE /C all Note: The UFI file identifies the RAID controllers, so you don’t...
  • Page 124 Appendix E: Using the Adaptec Flash Utility When prompted, insert the first firmware disk into your floppy disk drive. The AFU reads the first disk. When prompted, remove the first firmware disk and insert the second firmware disk into your floppy disk drive.
  • Page 125: Safety Information

    Put the controller down only on an antistatic surface such as the bag supplied in your kit. If you are returning the controller to Adaptec, put it back in its antistatic bag immediately.
  • Page 126: Technical Specifications

    Technical Specifications In this appendix... Environmental Specifications ............127 DC Power Requirements ..............127 Current Requirements ..............127...
  • Page 127: Environmental Specifications

    5 V ± 5%, 3.3 V ± 10% Current Requirements Adaptec Model Maximum Current (A) Adaptec 4000SAS 1.5 A @ 3.3 VDC; 0.75 A @ 5.0 VDC Adaptec 4800SAS 1.4 A @ 3.3 VDC; 2.4 A @ 5.0 VDC Adaptec 4805SAS 1.5 A @ 3.3 VDC;...
  • Page 128 ACU script file syntax non-RAID scripts RAID 1 switches RAID 10 Adaptec Flash Utility. See AFU RAID 1E Adaptec RAID Controller RAID 5 Configuration utility. See RAID 50 ARCCONF RAID 5EE Adaptec RAID Controller utility...
  • Page 129 Index flashing installation options backplane connections installing battery backup module keyed features BBS Support setting modifying general settings modifying settings with -Select boards. See controllers utilities boot controller Physical Drives Display During bootable arrays POST setting creating RAID levels Removable Media Devices Boot Support setting resetting cables...
  • Page 130 Index firmware recovering from failure creating floppy disks rescanning firmware upgrades SAS identifiers flashing controllers floppy disks for firmware update verifying formatting disk drives drive requirements Drive’s Write Cache setting driver and operating system hard disk, hard disk drive, hard drive. installation See disk drive driver disk...
  • Page 131 Index links (SAS) RAID Linux RAID 0 driver installation RAID 1 OS installation RAID 10 Linux installation RAID 1E locked features RAID 5 RAID 50 RAID 5EE RAID 6 Managing RAID 60 Maximum Transfer Rate setting RAID 1E mirroring RAID 5EE RAID 6 RAID 60 RAID controllers.
  • Page 132 Serial Attached SCSI. See SAS Phy Rate setting Small Computer System Interface. SAS Address setting See SCSI SAS devices snapshots SATA software cables specifications disk drives storage management SATA controllers Adaptec RAID Controller utility cables Adaptec Storage Manager connecting disk drives disk drives ARCCONF...
  • Page 133 Index storage space SuSE updating firmware driver installation upgrading firmware SuSE installation utilities switches in ACU for DOS Adaptec RAID Controller system requirements utility ARCCONF technical specifications Technical Support Identification (TSID) number verifying disk drives terminology ICP Storage Manager tools...
  • Page 134 Adaptec, Inc. 691 South Milpitas Boulevard Milpitas, CA 95035 USA ©2005 Adaptec, Inc. All rights reserved. Adaptec and the Adaptec logo are trademarks of Adaptec, Inc. which may be registered in some jurisdictions. Part Number: CDP-00062-01-A, Rev. A LB 10/05...

Table of Contents
