Removing The Encoder; Fitting The Encoder - Fronius Testbox CMT-Encoder Operating Instructions Manual

Removing the en-
coder
(4)
(5)
(3)
(4)
Fitting the encod-
er
Pull the plug (1) out of the encoder
1
Pull out the encoder clip (2)
2
Undo the Allen screw (3)
3
Undo screws (4)
4
(2)
Pull off the encoder (5)
5
(1)
(2)
Pull out the encoder clip (1)
1
Place the encoder (2) on the drive unit
2
as shown
Push the encoder disc (3) towards the
3
(4) drive unit
- This centres the encoder
(1)
Tighten the screws (4), tightening tor-
(2)
4
que = 0.2 Nm
(3)
(1)
(4)
Connect the plug (5) as shown
5
Set the encoder (see "Setting the en-
6
coder")
(5)
31
