General

Device concept

Scope of supply

Information for
repair and set up
work

Material required

-
Warning notices A number of safety symbols can be seen on the device's rating plate. The safety symbols
affixed to the de- must NOT be removed or painted over. The symbols warn against operating the equipment
vice incorrectly, as this may result in serious injury and damage.
(1)
(3)
NOTE! The warranty does not cover repair or set up work that was not carried out
by the manufacturer.
Loctite 243
The CMT encoder testbox:
- Tests the encoder on the Robacta
Drive CMT unit
- Sets the parameters on the Robacta
Drive CMT unit encoder if it has been
replaced
(1) CMT encoder testbox
(2)
(2) MOTOR adapter (item number
43,0004,2713)
(3) Mains cable
(4) ENCODER adapter (item number
43,0004,4303)
(5) Operating instructions (not shown)
(4)
