Mains connection

The device is designed to run at the mains voltage indicated on the rating plate. The re-
quired fuse protection for the mains supply can be found in the "Technical data" section. If
there is no mains cable or mains plug on your device, fit one that conforms to national
standards.

Safety

26
Type
Testbox CMT-Encoder
Art.No.
A-4600 Wels
Ser.No.
www.fronius.com
IEC 61010-1 / EN 61000-6-4 / -6-2
U
1
1~
230 V
IP 20
50-60Hz
Do not dispose of used units with domestic waste.
Dispose of them according to safety rules.
Do not use the functions until you have fully read
all the operating instructions.
NOTE! Inadequately dimensioned electrical installations can cause serious dam-
age. The incoming mains lead and its fuse must be dimensioned to suit the local
power supply. The technical data shown on the rating plate applies.
WARNING! Incorrect operation or shoddy workmanship can cause serious injury
or damage. All functions described in the operating instructions may only be used
by trained and qualified personnel. All activities described in the operating instruc-
tions may only be carried out by trained and qualified personnel. Personnel car-
rying out these activities must have received training from Fronius in the correct
operation of the device. Do not use any of the functions described or carry out the
work described until you have fully read and understood the following documents:
- these operating instructions
- all the operating instructions for the system components, especially the safe-
ty rules
WARNING! Work that is carried out incorrectly can cause serious injury and dam-
age. Before working and performing tests on the Robacta Drive CMT unit:
- Turn the power source mains switch to the "O" position
- Disconnect the power source from the mains
- Ensure that the power source remains disconnected from the mains until all
work has been completed
- Remove the wire electrode from the hosepack
- Disconnect the Robacta Drive CMT unit from all system components
CAUTION! Risk of burns from hot welding torch components and hot coolant. Be-
fore commencing any of the work described in these operating instructions, allow
all welding torch components and the coolant to cool to room temperature (+25
°C, +77 °F).
