Replacing the encoder

Preparing the
drive unit
30
(1+2) (3) (2)
(1+2) (2)
(4)
Pierce the two seals (1)
1
Undo the four screws (2)
2
Take off the base plate (3) using a light
3
jerking movement
IMPORTANT! If a gasket is fitted, this must
remain on the motor housing.
Pull the electronics box backwards out
4
of the slot
Pull the plug (4) out of the RDIO 30 A
5
PC board
