Output data range setting

1.
2.
3.
B15 B14 B13 B12
CH7 CH6
R200
September 2010
Digital output data range for analog input can be set per channel.
When output data range is not set, all channels are set as 0~16000.
The following figure is an example for setting CH0~CH3 as -8000~8000,
CH4~CH7 as 0~10000.
B11 B10 B9
CH5 CH4
BIT
00 Unsigned value:0 ~ 16000
01 Signed value:-8000 ~ 8000
10 Precise value
11 Percentile value:0 ~ 10000
Analog Input Module 2MLF-AV8A, AC8A User's Guide
5. Configuration and Function of Internal Memory
5.5. PUT/GET function block use area (parameter area)
B8 B7 B6 B5
CH3 CH2
Description
