NHEA PLUS SE HANDS-FREE AUDIO TERMINAL

CHARACTERISTICS

- Nhea Plus SE hands-free audio terminal for Plus installation.
- Terminal with 4 common wire installation.
- Function and advanced programming access buttons (to customise terminal functions).
- Totally private conversation.
- Auto switch-on function.
- 'Doctor mode' function (automatic door opening, see p. 9).
- Intercom between two devices in the same apartment.
- Apartment front door call input.
- Call reception volume control (maximum and minimum).
- Audio volume control (maximum and minimum).
- Call volume adjustment: maximum, minimum and no volume 'night mode' (see p. 5 'function buttons').
- Exterior b utton input for d
- Output to auxiliary call repeater.
- Call to main and secondary guard unit.
- Panic call to guard units.
- Different ringtones to identify call origin: oor panel, guard unit, intercom and interior door of apartment 'HZ.'
- Activation of auxiliary functions: courtesy lights, second lock release, etc.
- Configuration of the terminal as a slave and intercom (quick programming mode).
- Door release button.
- Terminal status LED.

SYSTEM OPERATION

- To make a call, the visitor presses the button for the apartment, a number of audible tones indicate that the call is being
made and LED on the door panel illuminates. At this moment, the apartment's terminal receives the call. If the visitor
presses the button for another apartment by mistake, the call can be cancelled by pressing the button for the correct
apartment.
- In systems with several access doors, the other door panel(s) automatically disconnects. If another visitor attempts to
call, a number of telephone tones will indicate that the channel is busy and LED
- General entrance door panels (mode EL501): If the call is being made from the general entrance door panel, the
interior door panel of the building being called and other possible general entrance door panels automatically
disconnect. If another visitor attempts to call from either a busy interior door panel, a number of telephone tones will
indicate that the channel is busy and LED
panel, a number of telephone tones will indicate that the channel is busy and LED of the general entrance door panel
will blink for 3 seconds. The door panels of the other interior buildings will remain free to be used.
- General entrance door panels (mode EL501): If the call is made from an interior door panel, the other interior door
panels will remain free to be used. It is only possible to make calls to interior buildings from the general entrance door
panels when their door panels are not in use. If an attempt is made to make a call to a busy interior door panel, a
number of telephone tones will indicate that the channel is busy and LED
blink for 3 seconds.
- The call lasts for 45 seconds and the status LED of the master terminal will illuminate (green). If the call is not
answered within 45 seconds, the master terminal's status LED will illuminate (red), LED
off and the channel will be free.
- To establish communication, press button
terminal's status LED (green) and the door panel's LED will illuminate.
- Communication will last for one and a half minutes or until button
of the telephone (monitor) is replaced. After communication, the terminal's status LED will illuminate (red), the door
panel's LED will turn off and the channel will be free.
- To open the door, press door release button
the lock release for 3 seconds and LED
- A description of the function buttons can be found on p. 5.
oor panel oo release l k
d
of the door panel will illuminate, or from another general entrance door
of the terminal or lift the handset of the telephone (monitor), and the
will also illuminate for 3 seconds.
on the terminal is pressed again or the handset
during the call or communication processes: one press will activate
on the door panel will illuminate.
of the general entrance door panel will
on the door panel will turn
