- Page 1 V ideo door entry system with unpolarised 2 wire installation V2PLUS Instructions manual TV2PLUS ML rev.0210...
-
Page 2: Table Of Contents
With a 1 line distributor ....99-100 Power supply installation ......85 With a 4 line distributor ....101-104 Lock release installation ......85 With a.c lock release....105-106 Platea V2Plus monitor ........Troubleshooting hints ......107 Description..........86 Notes...........108-110 Function push buttons ......87 Compliance......... -
Page 3: System Characteristics
SYSTEM CHARACTERISTICS Video door entry system with simplified installation (2 wire bus without polarity 1 access door panel, (up to 3 access door panel with MC-V2Plus multiplexer) Up to 32 monitors or telephones per installation without using converters or multiplexers Up to 32 apartments with push button door panels and 32 apartments with coded panel (being necessary the use of digital converter CD-V2Plus). -
Page 4: Description
EL530 , on video systems with color camera. EL531 , on audio systems. EL540 Microprocessor circuit on audio and video systems EL500/V2PLUS Push buttons encoder EL516 on systems with more than eight push buttons... -
Page 5: Embedding Box Positioning
DOOR PANEL INSTALLATION mbedding box positioning 1850 1650 1450 The upper part of the door panel should be placed at 1,65m. height roughly The hole dimensions will depend on the number of door panel modules Modules Compact CE630 Model CE610 CE615 CE620 125 mm. -
Page 6: Embedding Box Installation
DOOR PANEL INSTALLATION lace the embedding box Pass the wiring through the hole made in the bottom part of the embedding box Level and flush the embedding box Once the embedding box is placed, remove the protective labels from the attaching door panel holes ssembly the door panel modules Insert the header DOWN marked in the lower module and fix it by screwing the... -
Page 7: Electronic Modules Assembly
EL500/V2PLUS microprocessor circuit and the EL516 push buttons encoders The EL500/V2PLUS circuit is to be assembled on the top of the embedding box Insert the circuit in the top flanges of the embedding box (1) Push-in the... -
Page 8: Door Panel Fixing
To hold the door panel on the embedding box, insert the hinges in the embedding box lockers as shown . Link the sound module with the EL500/V2PLUS microprocessor circuit by using the supplied flat cable . -
Page 9: Placing The Nameplate Labels
It's recommended to use wires with sections between 0,1 and 0.25mm section wist the call wires as shown The call wires will be connected to the EL500/V2PLUS microprocessor circuit or to the corresponding EL516 push buttons encoder IMPORTANT:... -
Page 10: Door Panel Installation
DOOR PANEL INSTALLATION ush buttons wiring Plug the push buttons connection cable to the CN6 connector of the EL500/V2PLUS microprocessor module; this cable has 10 conductors (P1 to P8, B and CP) for the connection of push buttons or EL516 encoders... -
Page 11: Push Buttons Coding
(apartments) is 32 if the installation uses distributors, or 16 if it does not (daisy chain Up to 8 EL516 encoders (requires the use of the multiplexer MC-V2Plus), can be used to increase the number of push buttons (apartments) to 120 if the installation uses distributors... -
Page 12: El500/V2 Plus Configuration
It is accessed by opening the terminal connection block protection cover . Set the master door panel to OFF, if there is a MC-V2Plus multiplexer with access doors panels in the installation or backbone, only one door panel can be configured as the master, the rest must be slaves and set to ON. -
Page 13: Lamps Wiring
Don't change JP1 jumper position JP1 and JP2 jumpers are placed on the left side of the sound module terminal connection block If the TF-104 transformer with alternating current lock release is also used, wire ~1/~2 terminals of the sound module with CV1/CV2 terminals respectively of the EL-500/V2Plus. inal adjustments Sound Module:... -
Page 14: Closing The Door Panel
POWER SUPPLY INSTALLATION etail of the FA-V2PLUS power supply installation Install the power supply in a dry and protected place without risk of drip or water projections. 3,5 x 45 DIN-7971 To avoid damage, the power supply must be firmly fixed. -
Page 15: Platea V2Plus Monitor
MONITOR DESCRIPTION escription of the Platea V2Plus monitor REF. PLATEA V2PLUS COD. 11784042 VERSIÓN: Nº SERIE: X.XX 00000000000 INTER SLAVE MASTER CODIGO / CODE ATENCIÓN Alta tensión. No abrir la tapa. ESCALERA PISO PUERTA Manipular sólo por personal STAIR FLOOR DOOR del servicio técnico. -
Page 16: Function Push Buttons
Set to OFF the rest of monitors, and with a multiplexer the monitors con- Factory default nected in riser without distributors (daisy chain). escription of the identification label For an easiest repair, replacement or increasement REF. PLATEA V2PLUS of the existing monitors, fill the identifying label COD. 11784042 information MASTER: m aster monitor VERSIÓN:... -
Page 17: Monitor Connection Block Description
CONNECTION BLOCK DESCRIPTION escription of the RCPL-V2Plus monitor connection block 50mm. 50mm. Presionar para abrir. Press to open. Colocar la parte superior de la regleta a 1,60m. del suelo. Place the top part of the monitor connector at 1,60m. from the floor. -
Page 18: Monitor Installation
MONITOR INSTALLATION ix the monitor connection block to the wall Avoid placing the monitor near sources of heat, in dusty locations or smoky environments To install the monitor directly over the wall, drill two holes of Ø6mm. and use the supplied screws The upper part of the monitor connection block must be placed at 1,60m. -
Page 19: Programming
Locate the configuration dip switch situated under the protection cover of the EL500/V2PLUS microprocessor circuit and set umber 2 to ON as described on page The door panel will reproduce a sound to advise that the system... -
Page 20: T-7822Vd
S+, S-: Connection to an S-45 call repeater JP3 configuration jumper: BUS: Digital communication bus HZ : Door bell push button input V2Plus system (video) PA, PB: Voltage free contacts (see page 96 . BUS: Digital communication bus 2Plus system (Audio) -
Page 21: Telephone Installation
TELEPHONE INSTALLATION ix the telephone to the wall It is necessary to open the telephone for wiring and fixing purposes To open the telephone, insert a plain screwdriver into the slots and gently lever as shown in the drawing Avoid placing the telephone near sources of heat, in dusty locations or smoky environments The telephone can be fixed using an electrical embedding box or directly on the wall, as shown on the picture If the telephone will be... -
Page 22: Programming
EL500/V2PLUS microprocessor circuit and set number 2 to ON as described on page 83 The door panel will reproduce a sound to advise that the... -
Page 23: Optional Connections
The lock release can be activated at any moment by using an external push button, that must be connected between 'CV1' and 'CV2' of the door panel This function will allows to exit from the building being not necessary the use of a key EL 500/V2PLUS oor bell push button connection. Platea V2Plus monitors and the T-7822VD telephones, incorporate as standards the call reception from the door bell push button. -
Page 24: Additional Monitor, Telephone Or
OPTIONAL CONNECTIONS onnecting a monitor, telephone or additional call repeater REMEMBER: The total number of elements per apartment (monitors, telephones or call repeaters) must never exceed three units. Additional monitor Platea V2Plus Platea V2Plus PA PB PA PB BUS IN... -
Page 25: Auxiliary Devices Activation
OPTIONAL CONNECTIONS latea V2Plus monitor auxiliary push button Activate the SAR-2Plus unit to switch on the ligths, etc. See document TSAR-2Plus for its connection and configuration. Activates the PA and PB contact closure of the monitor, so it can be used for switching on the lights, opening an additional... -
Page 26: Installation Diagrams
INSTALLATION DIAGRAMS onfiguring the end of line in the last monitor Platea V2Plus PA PB BUS IN BUS OUT Platea V2Plus PA PB BUS IN BUS OUT Master door panel FA-V2PLUS - - + CV1 +12 Main... - Page 27 aisy chain installation for a video door entry system without distributor and d .c lock release. The installation diagram shows the connection of a video door entry system with one door panel to access the building, and with a daisy chain installation without distributor and d.c.
- Page 28 INSTALLATION DIAGRAMS Insert a 120 ohm end of line resistor in the last distributor. Configuring the end of line in the last monitor. R.1 20 D1L-V2Plus Platea V2Plus End of line PA PB BUS IN BUS OUT D1L-V2Plus Platea V2Plus...
- Page 29 1 line distributor and d.c lock release The installation diagram shows the connection of a video door entry system with one door panel to access the building, with 1 line D1L-V2Plus distributors and d.c lock release IMPORTANT: In the output to the monitor/telephone of a...
- Page 30 INSTALLATION DIAGRAMS Insert a 120 ohm end of line resistor in the last distributor. Configuring the end of line in the last monitor. R.1 20 D4L-V2Plus Platea V2Plus Platea V2Plus End of line PA PB PA PB BUS IN BUS OUT...
- Page 31 4 line distributor and d.c. lock release The installation diagram shows the connection of a video door entry system with one door panel to access the building, with 4 line D4L-V2Plus distributors and d.c. lock release IMPORTANT: In the output to the monitor/telephone of a...
- Page 32 INSTALLATION DIAGRAMS Configuring the end of line in the last monitor. Platea V2Plus Platea V2Plus PA PB PA PB BUS IN BUS OUT BUS IN BUS OUT Platea V2Plus Platea V2Plus PA PB PA PB BUS IN BUS OUT BUS IN...
- Page 33 4 line distributor and d.c lock release The installation diagram shows the connection of a video door entry system with one door panel to access the building, two riser and one distributor of 4 line D4L-V2Plus with a daisy chain installation and d.c. lock release...
- Page 34 INSTALLATION DIAGRAMS Insert a 120 ohm end of line resistor in the last distributor. Configuring the end of line in the last monitor. R.1 20 D4L-V2Plus Platea V2Plus Platea V2Plus End of line PA PB PA PB BUS IN BUS OUT...
- Page 35 The installation diagram shows the connection of a video door entry system with one door panel to access the building, with 4 line D4L-V2Plus distributors and a.c lock release. Use the TF-104...
-
Page 36: Troubleshooting Hints
An easy way to check that the system is working properly is to disconnect the wiring from the door panel and to check the monitor directly connected to the EL500/V2Plus circuit A short circuit between different terminals of the installation will never damage the connected systems...
