RightAngle NewHeights Series Quick Start Manual
2-leg workstation
Hide thumbs
Also See for NewHeights Series:
- Assembly instructions manual (6 pages) ,
- Instructions (5 pages) ,
- Operation instructions (4 pages)
Table of Contents
Advertisement
Quick Links
NewHeights™ Series 4 Bonita ET 2-Leg Workstation
Failure to comply with or observe all assembly, safety, and operation instructions
and warnings regarding use of this product may result in serious property damage
or bodily injury.
Make sure no obstacles are in the desk's path and all cords are of appropriate length for the
desk. Always maintain a 1" clearance around the table to prevent pinching.
Never assemble (or disassemble) the table or components with the table plugged into a pow-
er outlet. This product is for use on a nominal 120-volt circuit and has a grounding plug. Make
sure that the product is connected to an outlet having the same configuration as the plug. No
adapter should be used with this product.
Warranty: raproducts.com/warranty
Instruction #53911 • Dated: 02/6/2018
1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RightAngle NewHeights Series
Summary of Contents for RightAngle NewHeights Series
- Page 1 NewHeights™ Series 4 Bonita ET 2-Leg Workstation Warranty: raproducts.com/warranty Failure to comply with or observe all assembly, safety, and operation instructions and warnings regarding use of this product may result in serious property damage or bodily injury. Make sure no obstacles are in the desk’s path and all cords are of appropriate length for the desk.
- Page 2 Tools Required for Assembly A. Power Driver with Adjustable Torque B. Tape Measure C. #2 Phillips Head Driver Bit D. #2 Square Head Drive Bit (Recommended) Hardware and Tools Included for Assembly (may have extra) E. 3/4” Wood Screw x42 1/4”x5/8”...
- Page 3 Important: Please be aware that ¾” screws are provided. If your worksurface is ¾” or thinner, you will need to supply your own hardware. Step 1 • Lay the worksurface on a protected surface with pilot holes facing up. Legs must be in •...
- Page 4 Step 3 • Tighten motor mounting bolts after hex rod is installed. Step 4 • Install u-channel. Tip: For proper alignment of pre-drilled holes, start screws but do not fully tighten until all are installed. K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 4 of 8...
- Page 5 Step 5 • Slide cross support over leg cross support brackets. Step 6 • Install bolts and do not fully tighten. K&A Manufacturing • 800.298.4351 • www.raproducts.com/install 5 of 8...
- Page 6 Step 7 • Install wood screws and tighten. Step 8 • Fully tighten bolts in cross support. Tighten bolts Step 9 Programmable Snap switch on Switch control box Note: if you have a programmable switch (shown), please refer to the installation instructions included the switch.
- Page 7 Step 10 • Install wire management J-channel and control box. J-channels Step 11 Control Box End View Power Cable Motor Cable Switch Cable J-Channel (Not in use with snap on switch) Wire Management Power Cable Route over U-Channel Motor Cable Route to J-Channel Note: if you have a then Control Box...
- Page 8 Hard reset: • Press and hold the down arrow button for 10 seconds until the control box clicks several times. Troubleshooting: If you are having any problems with the operation, contact RightAngle Products at 800.298.4351 or orders@raproducts.com. Optional Programmable Switch...
