RightAngle NewHeights RECTANGULAR 3-LEG WORKSTATION Assembly Instructions

K&A MANUFACTURING
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: 800.298.4351 FAX: 866.882.9475
www.raproducts.com
VERSION DATED: 5/10/13
PRE-INSTALLED
T-SLOT PLATE
DETAIL A
2
WORKSURFACE SUPPORT
9
10
11
15
14
INSTRUCTION # 52778

TOOLS REQUIRED FOR ASSEMBLY:

CORDLESS DRILL
#2 PHILLIPS HEAD DRIVER BIT OR
#2 SQUARE HEAD DRIVER BIT
7/32" HEX HEAD DRIVER BIT OR
ALLEN WRENCH PROVIDED
3/16" HEX HEAD DRIVER BIT
TAPE MEASURE
LEVEL
LOCATING THE CROSS SUPPORT
(SEE EXCEPTION IN STEP 3)
4
1
16
STEPS 1-4
HARDWARE PACK #
NewHeights™ RECTANGULAR 3-LEG WORKSTATION ASSEMBLY INSTRUCTIONS:

STEP 1: LAY THE WORKSURFACE 1

PILOT HOLES FACING UP. PLACE THE LEFT HAND COLUMN ASSEMBLY
THE RIGHT HAND COLUMN ASSEMBLY
4
ASSEMBLY ON THE WORKSURFACE AS SHOWN. ALIGN THE HOLES IN THE
WORKSURFACE SUPPORTS WITH THE PILOT HOLES IN THE WORKSURFACE.
THE MOTOR WIRES MUST FACE THE INSIDE OF THE WORKSTATION.

STEP 2:

WITH THE HELP OF AN ASSISTANT, PLACE (4) STAR WASHERS
(4) SOCKET SCREWS
OF THE CROSS SUPPORT
HEAD SOCKET SCREWS
CENTER OF THE CROSS SUPPORT. THREAD ALL (6) SOCKETSCREWS INTO
THE HOLES IN THE T-SLOT PLATES THAT ARE PRE-INSTALLED IN THE SLOTS IN
16
THE COLUMNS. SEE DETAIL A. DO NOT FULLY TIGHTEN.

STEP 3:

LEVEL THE CROSS SUPPORT
WORKSURFACE SUPPORTS AND FULLY TIGHTEN ALL THE SOCKET SCREWS
AND 15 . SEE THE DETAIL AT LEFT.
ON WHICH THE LifeBalance™ STATION IS BEING INSTALLED, THE CROSS
SUPPORT SHOULD BE ATTACHED RESTING ON THE FEET OF THE COLUMN
ASSEMBLIES TO ALLOW FOR CLEARANCE OF THE EQUIPMENT.
4.00

STEP 4:

INSERT AN END CAP
INSERT (2) SHORTY PLUGS
THE CROSS SUPPPORT.
ITEM # PART #
1 VARIES WORKSURFACE
2 VARIES NewHeights LEFT HAND COLUMN ASSY
3 VARIES NewHeights RIGHT HAND COLUMN ASSY
4 VARIES NewHeights CENTER COLUMN ASSY
5 800411 NewHeights/HOVER END CAP
6 50285 NewHeights HAND SWITCH
3
7 51951 WIRE MANAGEMENT J
8 51708 M5 x 18mm SQ/PH/WSHR HEAD WOOD SCREW
9 52477 3/8 INTERIOR TOOTH STAR WASHER
10 52470 3/8-16 x 3/8 BUTTON HEAD SOCKET SCREW
11 52059 5/8" SHORTY PLUG
12 50298 NewHeights CONTROL BOX
13 52498 7/32" ALLEN WRENCH
14 52425 3/8 x 1/2 x 1/8 HIGH COLLAR LOCK WASHER
15 52424 3/8-16 X 1/2 LOW HEAD SOCKET SCREW
800532 NewHeights 96" CROSS SUPPORT RECTANGULAR
16
3-LEG (91" ACTUAL)
5
ON A PROTECTED SURFACE WITH THE
3 , AND THE CENTER COLUMN
10 . INSERT THESE THROUGH THE HOLES AT THE ENDS
16
. PLACE (2) LOCK WASHERS
15 . INSERT THESE THROUGH THE HOLES AT THE
16
AT 4" ABOVE THE BOTTOM OF THE
SPECIAL EXCEPTION: ON WORKSTATIONS
5 INTO EACH END OF THE CROSS SUPPORT
11 INTO THE ACCESS HOLES AT THE CENTER OF
DESCRIPTION
2
,
9
ON
14
ON (2) LOW
10
16 .
QTY.
1
1
1
1
2
1
3
29
4
4
2
1
1
2
2
1
PAGE 1 OF 3
