APOLLO Windows XP Embedded Quickstart
For this example we will assume that the drive letters are the same as shown in the
screenshot. If they differ on your system, you will have to change the commands
accordingly.
8 Change to your DVD drive by typing D:
9 Change directory to the folder containing the CFCLONE tool by typing
CD\TOOLS\CFCLONE
10 Type the following command to copy the image from a network location to the flash
disk: CFCLONE \\MYSERVER\MYSHARE\MasterImage.bin E:
11 When the CFCLONE tool has finished, type EXIT.
12 Click on the START button, and select TURN OFF COMPUTER.
13 Power on the APOLLO, and press F2 to enter the BIOS.
© 2007 Eurotech Ltd Issue E
The Intel USB Flash Disk is the device which is 1956MB in total size. In
the example shown above, it has the drive letter E: assigned to it, and is
highlighted in blue. If your Intel USB Flash Disk does not have a drive
letter allocated, you will need to follow the instructions in the
your Intel USB Flash Disk
You will need to replace the \\MYSERVER\MYSHARE\ with the name of
your own network location.
If you wish to create more than one cloned flash disk, you can click on
the Safely Remove Hardware icon on the taskbar near the clock, and
then Safely remove USB Mass Storage Device – Drive(E:). You will
NOT see a confirmation box that it is safe to remove it, but after waiting
a few seconds you can physically remove the flash disk from the
APOLLO and plug in the next one to be programmed.
Security and image duplication
section, on page 37.
Preparing
46
