- Page 1 USER’S MANUAL ACS-5151 50 Watt PC/104 Automotive Power Supply Module Vin = 8 ~ 40VDC Rev. 1.0 - November 2008 - ETH_ACS-5151_USM1.0 DIGITAL TECHNOLOGIES FOR A BETTER WORLD www.eurotech.com...
- Page 2 This product is supplied with a limited warranty. The product warranty covers failure of any Eurotech manufactured product caused by manufacturing defects. Eurotech will make all reasonable effort to repair the product or replace it with an equivalent alternative. Eurotech reserves the right to replace the returned product with an alternative variant or an equivalent fit, form and functional product.
-
Page 3: Introduction
Module specific Dependent on module installed Not Connected Reserved Use reserved to Eurotech, must remain unconnected Active low signal Warnings and Important Notices: Within this manual you will find the following tables, please ensure that you read and understand these as they are intended to highlight potential risks or precautions that should be taken. -
Page 4: Technical Assistance
If you have any technical questions or if you cannot isolate a problem with your device, please e-mail the Eurotech Technical Support Team: email: techsupp@eurotech.com Before returning any Eurotech product, for any reason, you must e-mail the Eurotech Technical Support Team on the above email address, giving the following information; you will then be sent an RMA number (Returned Material Authorization) for the return of the material: •... -
Page 5: Table Of Contents
Jumper Layout ...............................11 Chapter 3 Connector Description ......................13 Connector Layout ............................13 How to connect the ACS-5151 to other PC/104 & PC/104-Plus devices............14 The ISA Bus: J1 and J2............................. 14 The stack assembly..............................16 Power input connector: +8 to +40V........................17 Output connector: +12V..........................17 +3.3V Output connector..........................18... - Page 6 ACS-5151 – User’s Manual Appendix ..............................25 A.1. Mechanical Dimensions ........................25 A.2. Manual Revision History........................26 Eurotech Group Worldwide presence ......................27...
-
Page 7: Chapter 1 Product Overview
In the following paragraphs, you will find a brief description of the ACS-5151 characteristics. The ACS-5151 vehicle power supply is designed to meet the system design requirements of vehicle, machine, industrial, and mobile installations. It offers resistance to high levels of shock and vibration and has a rugged mechanical design. -
Page 8: Product Definition
ACS-5151 – User’s Manual Product Definition General Features: Architecture • PC/104 compliant Voltage Input: • VIN=+8 VDC to +40 VDC • High transient voltage margin (50V 1ms) Voltage Output: • +5V, +12V, +3.3VDC Power Output: • Up to 50 Watts Combined (+5V@10A, +3.3V@2A, +12V@2A) Input Protection: •... -
Page 9: Block Diagram
8-40V DC Input 50 Watt Input Linear +3.3VDC Filter DC/DC Protection Regulator Output Converter +5 VDC Filter DC/DC +12 VDC Filter Converter Filter +12 VDC +5 VDC ISA Bus Figure 2. Functional block diagram of the ACS-5151 vehicle class power supply... -
Page 10: Electrical And Environmental Specifications
ACS-5151 – User’s Manual Electrical and Environmental Specifications Operating Characteristics Electrical Operating Characteristics Parameter Nominal [VDC] Specification [+/-%] Minimum [VDC] Maximum [VDC] Voltage Output +3.3 3.25 3.35 +5.0 4.75 5.25 +12.0 -4.2 /+1.6 11.5 12.2 Voltage Input +12.0 or +24.0 +8.0... -
Page 11: Chapter 2 Jumper Description
ACS-5151 – User’s Manual Chapter 2 Jumper Description Jumper Layout Figure 3. Jumpers and solder jumpers Label Function Type Options Factory Default /SHDN Shutdown Control 2pin jumper Closed: Turns off the complete power supply Open Open: Power supply module fully operational Table 1. -
Page 13: Chapter 3 Connector Description
ACS-5151 – User’s Manual Chapter 3 Connector Description Connector Layout INPUT +12V +3.3V J1 & J2 LED1 LED2 Figure 4. Connector layout Connector Function J1 & J2 ISA BUS (PC/XT) INPUT + 8 to +40V DC input +3.3V +3.3V screw terminal plug... -
Page 14: How To Connect The Acs-5151 To Other Pc/104 & Pc/104-Plus Devices
ACS-5151 – User’s Manual How to connect the ACS-5151 to other PC/104 & PC/104- Plus devices The ISA Bus: J1 and J2 Connectors J1 and J2 carry the signals for the ISA Bus. These signals match the definitions of the IEEE P996 standard. - Page 15 ISA Bus MEMR# ISA Bus Not Connected ISA Bus DRQ0 ISA Bus Ground 3 Table 4. J2 pinout Note: For further information regarding the ISA and PCI bus, please visit the Eurotech website (http://www.eurotech.com/), referring to the section titled “Industry Standards.”...
-
Page 16: The Stack Assembly
ACS-5151 – User’s Manual The stack assembly The ISA and PCI bus connectors of the module are designed to allow it to be connected with other PC/104 and/or PC/104-Plus devices, we recommend users to follow this procedure to ensure that stacked modules are not damaged. -
Page 17: Power Input Connector: +8 To +40V
Connecting raw input power to the ACS-5151 power supply and system. Description: The ACS-5151 accepts a wide input voltage range from +8V to +40V DC. This makes it the ideal power supply for automotive installations requiring compliance with EN50155. The input is reverse voltage protected up to 45V. -
Page 18: Output Connector
ACS-5151 – User’s Manual +3.3V Output connector +3.3V Figure 9. +3.3V output connector Use: +3.3Volt Output Description: A +3.3V linear regulator is cascaded on the +5V regulator output. This output is only available on this connector. +3.3V is not supplied to the PC/104 bus. The maximum output available current is 2A. This output... -
Page 19: Output Connector
ACS-5151 – User’s Manual +5V Output connector Figure 10. +5V output connector Use: +5.0Volt Output Description: A 5 Volt / 50 Watt switching DC/DC converter is used to power your complete 5 Volt system. This converter feeds power into the PC/104 bus pins and is available for peripheral device connection on the locking screw terminal block as shown in Figure 10. -
Page 21: Chapter 4 Power Supply Description
All the power outputs from the onboard DC/DC converter subsystems are filtered using power ferrites reducing emissions in the frequency range of 30 to 150MHz. The ACS-5151 will exceed the requirements of the EC low voltage directives for CE compliance. An input filter specially dimensioned for the ACS-5151 power supply ensures compatibility with EN-55022 class B or MIL-STD-461 requirements for conducted and radiated emissions. -
Page 22: Dc/Dc Step Down Converter Module
(Refer to the LED Description for location information.) Current Limit To protect the ACS-5151 against fault or error conditions the +5V DC/DC converter circuit is equipped with a current limiter to provide continuous overload protection. After reaching the current limit point (typically 5 - 10% exceeding the rated maximum current), the output voltage will vary between the rated nominal output and zero depending on the level of overload. -
Page 23: Status Led Indicators
Figure 13. Status LED locations Use: Board Status Description: There are two green status LED’s located next to the PC/104 bus connector these are used to indicate the status and state of the ACS-5151. LED Name Status Description LED1 +5V OK... -
Page 25: Appendix
ACS-5151 – User’s Manual Appendix A.1. Mechanical Dimensions 84.3 PAD 84.3 THRU 96.0 90.8 84.3 79.2 74.1 55.4 40.2 25.0 Dimensions are in millimetres Figure 14. ACS-5151 Board dimensions Note: For further information about the mechanical dimensions of ISA and PCI buses... -
Page 26: Manual Revision History
ACS-5151 – User’s Manual A.2. Manual Revision History REVISION DESCRIPTION DATE First Release November 2008... -
Page 27: Eurotech Group Worldwide Presence
Eurotech Group Worldwide presence EUROPE AMERICAS ASIA Central & Southern Europe North America EUROTECH Italy EUROTECH Inc ADVANET Japan tel. +39 0433.485.411 toll free +1 888.941.2224 tel. +81 86.245.2861 fax +39 0433.485.499 tel. +1 301.490.4007 fax +81 86.245.2860 e-mail: sales-it@eurotech.com fax +1 301.490.4582... - Page 28 www.eurotech.com...
