Unpacking And Connecting Up; Using A Vga Monitor - Eurotech Apollo Quick Start Manual

APOLLO Windows XP Embedded Quickstart

Unpacking and connecting up

Eurotech Ltd's Windows XP Embedded Development Kits are shipped 'ready to run'.
You simply remove the various items from their packaging and connect them up.

Using a VGA monitor

If you are using a VGA monitor, you can get started quickly and ensure everything is
connected properly by referring to the diagram and procedure below.
© 2007 Eurotech Ltd Issue E
APOLLO
breakout
board
Unpacking and connecting up
On/off
Flash disk
Pin 1 of ribbon this end
USB ports can be used
for keyboard or mouse
10
