  • Page 1 USER MANUAL CPU-1440 Development Kit Rev. 1.0 – Mars 2011 - ETH_CPU-1440-DEVKIT_USM...
  • Page 2 The warranty on all third party manufactured products utilised by Eurotech is limited to 1 year. Eurotech will make all reasonable effort to repair the product or replace it with an identical variant. Eurotech reserves the right to replace the returned product with an alternative variant or an equivalent fit, form and functional product.

  • Page 3: Table Of Contents

    Contents Contents Handling your board safely ....................4 Conventions........................... 4 Introduction..........................5 CPU-1440 Development Kit features ..................7 CPU module ......................7 CPU-1440 PC/104+ board ..................7 CPU-1440-Breakout board..................8 Display set (LCD variant only)..................9 Software specification ......................9 Operating system support ..................

  • Page 4: Handling Your Board Safely

    The battery is inserted in a socket and can be replaced with a 3.0V Lithium CR2032 Coin Cell. Packaging Please ensure that, should a board need to be returned to Eurotech, it is adequately packed, preferably in the original packing material. Electromagnetic compatibility (EMC) The CPU-1440 is classified as a component with regard to the European Community EMC regulations and it is the user’s responsibility to ensure that systems using the...

  • Page 5: Introduction

    Introduction The CPU-1440 development kit offers a ready-to-run, rapid application development environment which saves valuable engineering time. The DevKit contains the CPU-1440 module and its heat sink and an I/O breakout board. The CPU-1440 development kit supports the following features: PC/104-Plus (PCI bus).
  • Page 6 CPU-1440 Dev Kit user manual CPU-1440 development kit Issue A...

  • Page 7: Cpu-1440 Development Kit Features

    CPU-1440 Dev Kit user manual CPU-1440 Development Kit features CPU-1440 PC/104+ board Processor DM&P Vortex86DX • 600MHz • 2x16KB L1 cache, 256KB L2 cache • System memory DDR2 SDRAM 128 or 512 MB (300MHz) • BIOS General Software Embedded BIOS •...

  • Page 8: Cpu-1440-Breakout Board

    CPU-1440 Dev Kit user manual Power supply 5V only operation • Power consumption less than 4W • External battery for RTC backup • Mechanical PC/104-Plus form factor, 97x100 mm • CPU-1440-Breakout board Power supply +5V operation (Power brick supply input).

  • Page 9: Display Set (Lcd Variant Only)

    CPU-1440 Dev Kit user manual Display set Flat panel display 8.4 inch LVDS 24bit FPD (800 x 600 pixels). • Inverter +5V operation FPD inverter. • Touchscreen 8.4 inch 4 wire resistive touchscreen. • Touchscreen controller Eurotech TSC1 RS232 touchscreen controller.

  • Page 10: Software Specification

    Linux AEL. • DOS 6.22. • Eurotech provides Linux and CE development kits which can be loaded from an external Compact Flash. Drivers All system components have drivers available for Windows CE and Linux. Refer to the relevant Software manual for more information.

  • Page 11: Hardware Specification

    CPU-1440 Dev Kit user manual Hardware specification What’s in the Kit? Perspex base fitted with the CPU-1440 and Breakout board. • Perspex panel with the 8.4” flat panel display, inverter and TSC1 mounted on it. • All interconnecting cables. •...

  • Page 12: Expansion Buses

    A standard stack-through connector for the PCI bus (4x30-pin, 2mm pitch) is used for this interface. The CPU-1440 board supplies the 3.3V and VIO pins with a 3.3V voltage. Total connected boards consumption must be less than 2.5A. +12V, -12V and -5V are not available, if you require it, it must be supplied directly to the PC/104-Plus.

  • Page 13: Ethernet

    A LED is present on the CPU-1440-Breakout and signals access to the IDE bus. SPI Flash Drive The CPU-1440 board integrates a 2MB bootable SPI flash drive. It is recognized by the BIOS and can be used to store a small DOS application. By default, a DOS 6.22 version is installed on the SPI Flash Drive.

  • Page 14: Gpio

    Fitting a jumper sets the logic level low (LED ON). Power requirements The CPU-1440 board operates from +5V (+/-5%) power input. All other supply rails are generated on-board. An external coin cell battery input is available on the breakout board.

  • Page 15: Connectors And Jumpers

    CPU-1440 Dev Kit user manual Connectors and jumpers CPU-1440-Breakout The following diagrams show the location of the connectors and jumpers on the CPU-1440- Breakout. Top view J20 J16 Digital input Digital Output/Input Status IDE Reset button selection jumpers Led indication...
  • Page 16 CPU-1440 Dev Kit user manual Summary of connectors and jumpers The following table lists the connectors on the CPU-1440-Breakout: Connector Function Connector details in section DC_IN J30 – DC_IN, page 18 PS/2 mouse and keyboard J4 - PS/2 mouse and keyboard and VGA,...
  • Page 17 CPU-1440 Dev Kit user manual The following table lists the jumpers on the CPU-1440-Breakout: Jumper Function Jumper details in section Enable inputs JP1 – BAT-EN, page 28 Master/Slave IDE JP2 – BEEP-EN, page 28 Issue A...
  • Page 18 CPU-1440 Dev Kit user manual Connectors There are 25 connectors on the CPU-1440-Breakout; the use of each one is explained below. J30 – DC_IN Socket : 2.5mm DC Jack socket. Mating plug : 2.5mm DC Jack plug. Signal name Positive terminal (+5V)
  • Page 19 CPU-1440 Dev Kit user manual J14 – GPIO connector Connector : Phoenix contact MCDN 1.5/5-G1-3,5 P26THR. Mating Plugs : Phoenix contact FMCD 1,5/5-ST-3,5. Signal name Signal name DOUT0 DIN0 DOUT1 DIN1 DOUT2 DIN2 DOUT3 DIN3 J26 – Ethernet Connector : COMBO RJ45 socket and dual stacked USB type A.
  • Page 20 CPU-1440 Dev Kit user manual J7 – COM2 Connector : Single SUB D9 male. Mating socket : SUB D9 female. (top) Signal name J1 – COM3/COM4 Connector : Dual stacked SUB D9 male. Mating socket : SUB D9 female. (top)
  • Page 21 CPU-1440 Dev Kit user manual J2 – USB0/USB1 Connector : Dual stacked USB type A. Mating plug : USB type A plug. (top) Signal name (bottom) Signal name J3 – USB2/USB3 Connector : Dual stacked USB type A. Mating plug : USB type A plug.
  • Page 22 CPU-1440 Dev Kit user manual J16 – LVDS Display Connector : FI-SE20P-HFE. Mating plugs : HIROSE DF14-20S-1.25C. Signal name Signal name LVDS_D3+ LVDS_D3- LVDS_D1+ LVDS_D1- LCDVCC LVDS_D0+ LVDS_CLK+ LVDS_D0- LVDS_CLK- LVDS_D2+ LCDVCC LVDS_D2- LCDVCC Issue A...
  • Page 23 CPU-1440 Dev Kit user manual J20 – TSC1 Power Connector : MKDS1/2-3.81 Signal name J15 – LVDS Backlight connector Connector : simple breakable connection strip 2.54mm. Mating Housing : to be found. Signal name VLVDS VLVDS FPEN J12 – Keyboard/Mouse/Reset header Connector : ITT CANON ZDE9P-1AKN-146, 10-way 2.54mm (.0787") header.
  • Page 24 CPU-1440 Dev Kit user manual J19 – VGA header Connector : ITT CANON ZDE9P-1AKN-146, 10-way 2.54mm (.0787") header. Signal name Signal name VSYNC HSYNC BLUE GREEN J14 – GPIO header Connector : SAMTEC tmm-110-06-G-D-SM. Signal name Signal name DOUT0 DOUT1...
  • Page 25 CPU-1440 Dev Kit user manual J9 – Ethernet header Connector : ITT CANON ZDE9P-1AKN-146, 10-way 2.54mm (.0787") header. Signal name Signal name LEDACT Issue A...
  • Page 26 CPU-1440 Dev Kit user manual J8 –COM2 header Connector : SAMTEC TMM-105-06-G-D-SM. Signal name Signal name J6 – COM3/COM4 header Connector : SAMTEC TMM-110-06-G-D-SM. Signal name Signal name DCD3 DSR3 RTS3 CTS3 DTR3 DCD4 DSR4 RTS4 CTS4 DTR4 Issue A...
  • Page 27 CPU-1440 Dev Kit user manual J18 – LVDS/USB2/USB3 header Connector : SAMTEC TMM-113-06-G-D-SM. Signal name Signal name LVDS_D0+ LVDS_D0- LVDS_D1+ LVDS_D1- DTR3 VDD1 LVDS_D3+ LVDS_D3- LVDS_D2+ LVDS_D2- LVDS_CLK+ LVDS_CLK- FPEN VDD1 J17 – US0/USB1 Connector : SAMTEC TMM-104-06-G-D-SM. Signal name Signal name J5 –...
  • Page 28 CPU-1440 Dev Kit user manual J10, J27 – IDE header and IDE port Connector : SAMTEC TMM-122-06-G-D-SM. Signal name Signal name CBLID /HD_ACT J29 – USB Device Connector : SAMTEC, ESQ-103-12-L-S. Signal name Issue A...
  • Page 29 CPU-1440 Dev Kit user manual Jumpers There are two jumpers on the CPU-1440-Breakout; the use of each one is explained below. W2 – MASTER/SLAVE option for Compact Flash socket JP1 function table: Position Function Compact Flash Master Compact Flash Slave J23 –...

  • Page 30: Appendix A - Reference Information

    CPU-1440 Dev Kit user manual Appendix A – Reference information Product information Product notices, updated drivers, support material: www.eurotech.com PCI special interest group PCI Bus specification and list of manufacturers: www.pcisig.org USB information Universal Serial Bus (USB) specification and product information: www.usb.org...

  • Page 31: Appendix B - Rohs Compliance

    July 2006. The CPU-1440 board shall be designed using RoHS compliant components, and manufactured to comply with the RoHS Directive. Eurotech has based its material content knowledge on a combination of information provided by third parties and auditing our suppliers and sub-contractor’s operational activities and arrangements. This information is archived within the associated Technical Construction File.

  • Page 32: Eurotech Group Worldwide Presence

    Eurotech Group Worldwide presence AMERICAS ASIA EUROPE Japan Italy EUROTECH ADVANET EUROTECH Toll free +1 888.941.2224 Tel. +81 86.245.2861 Tel. +39 0433.485.411 Tel. +1 301.490.4007 +81 86.245.2860 +39 0433.485.499 +1 301.490.4582 E-mail: sales@advanet.co.jp E-mail: sales.it@eurotech.com E-mail: sales.us@eurotech.com E-mail: tsupport@advanet.co.jp E-mail: support.it@eurotech.com E-mail: support.us@eurotech.com...
  • Page 33 www.eurotech.com...
