APOLLO Windows XP Embedded Quickstart

Using a flat panel monitor

If you are using a flat panel monitor, you can get started quickly by referring to the
following diagram and procedure. For details of connections for the mouse, keyboard
and breakout board, see the diagram on page 11.
Backlight inverter
(safety cover not
shown for clarity)
Backlight inverter
cable
LVSD cable
J15 backlight
connector
COM 3
© 2007 Eurotech Ltd Issue E
15" LCD enclosure
J17
LVDS
Unpacking and connecting up
TSC1
8-wire touch ribbon cable
COMMS cable
TSC1 power cable (+5V DC)
ATX
CONN
Power
supply
12
