APOLLO Windows XP Embedded Quickstart
14 When prompted, enter a meaningful description of the image contents. This is for
your own reference only.
15 When the CFCLONE tool has finished, type EXIT.
16 Click on the START button, and select TURN OFF COMPUTER.
17 Power on the APOLLO, and press F2 to enter the BIOS.
18 Navigate to the Boot section using the
Hard Disk is selected as the first boot device. If you need to change the order, you
can do so using the + and – keys.
19 Navigate to the Exit section using the
Changes and press Enter.
The file that was created by the CFCLONE tool is your master image. This file must be
kept safe.
Creating the clone Flash Disk from the master
To copy the master image onto another flash disk (the clone), follow these steps:
1 Connect a DVD reader to the IDE connector on the APOLLO. If you want to store
your master image on a hard disk, also connect one now. This example will
assume that the image is being stored on a network location called
\\MYSERVER\MYSHARE.
2 Power on the APOLLO, and press F2 to enter the BIOS.
3 Navigate to the Boot section using the
CD-ROM Drive is selected as the first boot device. If you need to change the order,
you can do so using the + and – keys.
4 At this point, insert the APOLLO Windows XP Embedded Development Kit DVD
into the DVD reader.
5 Navigate to the Exit section using the
Changes and press Enter.
6 It will take approximately 3 minutes to boot the image of XP Embedded contained
on the DVD.
7 Click on the START button, and select COMMAND PROMPT.
Refer to the screenshot overleaf and type the commands shown in red to
determine the drive letters allocated to each drive.
© 2007 Eurotech Ltd Issue E
If a window appears with the message "This disk or device contains
more than one type of content. What do you want Windows to do?" click
the Cancel button.
Security and image duplication
and arrow keys, and make sure that
and arrow keys, select Exit Saving
and arrow keys, and make sure that
and arrow keys, select Exit Saving
