APOLLO Windows XP Embedded Quickstart
To unpack and connect up the APOLLO, follow these steps:
1 Plug one end of the flat panel interface cable into the APOLLO flat panel connector
J17 LVDS, and the other end into the flat panel.
2 Plug one end of the flat panel backlight cable into the APOLLO backlight connector
J15 B/L, and plug the other end into the backlight inverter.
3 If the touchscreen is to be used:
•
Use the serial adapter cables provided to connect the 9-way D-type on the
TSC1 to COM3 (J22) on the APOLLO.
•
Connect the touchscreen to the TSC1 using the 8-way ribbon cable.
•
Connect the TSC1 to the power supply.
© 2007 Eurotech Ltd Issue E
Make sure the power is off while connecting the LCD, as the backlight
inverter generates high voltages.
Pin 1 is marked on the touchscreen and the cable, but it can be
difficult to see.
Unpacking and connecting up
