- Page 1 OPERATION MANUAL D-CUT Flooring Cutter MD-630 www.dcutproducts.com...
- Page 2 7. Make sure tool is secure. Operate only on a firm substrate or solid stand. 8. Use the right tool. Do not force the D-Cut Multi-flooring Cutter or use it for a job for which it was not designed; use only on approved materials.
- Page 3 CUTTING AND C Installation Install the wheel assembly to the cutter base with provided bolts and nuts as shown. Then insert the handle into the handle base as show and tighten provided screw. Warning: Do not put your fingers against the sharp edge of the blade at any time.
- Page 4 Changing the Blade Use the provided Allan wrench to remove the ten screws, then hold the blade by each end and carefully move the blade out of blade holder. Note: the flat side of the blade should face the working table when install a new blade.
-
Page 5: Parts List
PARTS LIST... - Page 6 PARTS LIST Parts Q’ty Parts Q’ty Screw M6 × 12 Screw M8 Washer Φ6 Handle A Rubber Feet Handle B Hex Bolt M8 × 55 Nut M4 Left Wheel Base Right ABS Handle Right Wheel Base Screw M4 ×30 Hex Bolt M8 × 40 Left ABS Handle Carry Wheel Guider Bar...
