- Page 1 OPERATION MANUAL D-CUT Flooring Cutter MD-330 www.dcutproducts.com...
- Page 2 7. Make sure tool is secure. Operate only on a firm substrate or solid stand. 8. Use the right tool. Do not force the D-Cut Multi-flooring Cutter or use it for a job for which it was not designed; use only on approved materials.
- Page 3 CUTTING AND C Installation Install the table to the cutter base with provided screws and bolts as shown. Then insert the handle into the handle base as show and tighten provided screw. Warning: Do not put your fingers against the sharp edge of the blade at any time.
- Page 4 Changing the Blade Use the provided Allan wrench to remove the five screws, then hold the blade by each end and carefully move the blade out of blade holder. Note: the flat side of the blade facing the table. Warning: Do not put your fingers against the sharp edge of the blade at any time.
-
Page 5: Parts List
PARTS LIST... - Page 6 PARTS LIST Parts Q’ty Parts Q’ty Screw M5 × 10 Handle B Washer Nut M4 Φ5 Rubber Feet Right ABS Handle Bolt M4 × 30 Hex Bolt M8 × 55 Left ABS Handle Guide Bar Hex Bolt M8 × 50 Main Base Screw M5 ×...
