ISOMETER® isoES425
Insulation monitoring device for unearthed
AC, AC/DC and DC power supplies (IT systems) for energy
storage up to AC/DC 400 V
Software version: D0471 V1.xx
This operating manual is designed for electrically skilled persons working in
electrical engineering and electronics! It does not replace the operating ma-
nual. Make sure that the personnel has read this manual and understood all
instructions relating to safety.
The manual can be found at:
www.bender.de/en/service-support/downloads

1. Intended use

The ISOMETER® isoES425 monitors the insulation resistance R
AC, AC/DC and DC power supplies (IT systems) for energry storage up to
mains voltages of AC/DC 400 V. In order to meet the requirements of appli-
cable standards, customised parameter settings must be made on the equip-
ment in order to adapt it to local equipment and operating conditions. Please
heed the limits of the area of application indicated in the technical specifica-
tions.
Any use other than that described in this quickstart is regarded as improper.
20
To ensure that the ISOMETER® functions correctly, an internal
resistance of 1 kΩ must exist between L1/+ and L2/- via the
the source (e.g. the transformer) or the load.
In the event of an alarm message, the insulation fault should
be eliminated as quickly as possible.
isoES425_D00214_00_Q_DEEN/08.2017
