BrandMotion FLTW-7690 Installation Instructions

Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit:
Rear View mirror
Power/Video harness
D-tab (only use it you don't have a factory
mounted D-tab)
Wire guide for mirror to headliner
These instructions
Safety Precautions:
• Work in well ventilated area that is clear of obstructions.
• Secure vehicle with tire chucks in both front and rear of tires.
• Turn vehicle accessories OFF and ensure ignition key is in OFF position.
• Wear safety goggles and snug fitting clothes.
• Use tools only for their intended purpose and which are in good repair.
• Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions. For the latest full color
instructions, as well as an installation video, please visit www.brandmotion.com
FLTW-7690 instructions 9-23-16.doc
4.3" display Mirror w/ 2 dual video inputs
(Kit # FLTW-7690)
INSTALLATION INSTRUCTIONS
Tools & Supplies Needed:
Wire strippers
Wire cutters
Electrical tape
Zip ties
Plastic panel removal tools
Digital Volt Meter / BCM safe test light
Screwdriver
Socket set
Wrench
Page 1 of 2 GS
