IBM Power Systems 9009-41A Manual page 90

System backplane
Hide thumbs Also See for Power Systems 9009-41A:
Table of Contents

Advertisement

Figure 75. Installing the system processor module
e) Open the latches that hold the system processor module in the supplied removal tool (A) as
shown in the following figure. Push down on the ring (B) while pressing in on the tabs (C).
76 Power Systems: System backplane
