Power Systems
NVMe M.2 carrier cards and flash
modules for the 9009-41A, 9009-42A, or
9223-42H
IBM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9009-41A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBM 9009-41A

Summary of Contents for IBM 9009-41A

  • Page 1 Power Systems NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 2 Note Before using this information and the product it supports, read the information in “Safety notices” on page v, “Notices” on page 77, the IBM Systems Safety Notices manual, G229-9054, and the IBM Environmental Notices and User Guide, Z125–5823. ®...

  • Page 3: Table Of Contents

    Permanently removing an NVMe M.2 carrier card and flash module..........58 Preparing the system for operation..................... 69 Related procedures............................75 Checking the amount of remaining life in NVMe devices..............75 Removing an operational NVMe device from an IBM i logical partition..........75 Notices........................77 Privacy policy considerations ........................78 Trademarks..............................78 Electronic emission notices........................78...
  • Page 4 iv  ...

  • Page 5: Safety Notices

    Das Produkt ist nicht für den Einsatz an Bildschirmarbeitsplätzen im Sinne § 2 der Bildschirmarbeitsverordnung geeignet. Laser safety information IBM servers can use I/O cards or features that are fiber-optic based and that utilize lasers or LEDs. Laser compliance IBM servers may be installed inside or outside of an IT equipment rack.
  • Page 6 • Each rack cabinet might have more than one power cord. – For AC powered racks, be sure to disconnect all power cords in the rack cabinet when directed to disconnect power during servicing. vi  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 7 – For racks with a DC power distribution panel (PDP), turn off the circuit breaker that controls the power to the system unit(s), or disconnect the customer’s DC power source, when directed to disconnect power during servicing. • Connect all devices installed in a rack cabinet to power devices installed in the same rack cabinet.
  • Page 8 (for example, when working from a ladder). Stability hazard: • The rack may tip over causing serious personal injury. • Before extending the rack to the installation position, read the installation instructions. viii  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 9 • Do not put any load on the slide-rail mounted equipment mounted in the installation position. • Do not leave the slide-rail mounted equipment in the installation position. (L002) (L003) Safety notices  ix...
  • Page 10 There are no serviceable parts inside the device. • Use of the controls or adjustments or performance of procedures other than those specified herein might result in hazardous radiation exposure. (C026) x  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 11 Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call.
  • Page 12 Freewheeling will cause uneven cable wrapping around winch drum, damage cable, and may cause serious injury. • This TOOL must be maintained correctly for IBM Service personnel to use it. IBM shall inspect condition and verify maintenance history before operation. Personnel reserve the right not to use TOOL if inadequate.
  • Page 13 The dc-powered system employs an isolated DC return (DC-I) design. The DC battery return terminal shall not be connected to the chassis or frame ground. The dc-powered system is intended to be installed in a common bonding network (CBN) as described in GR-1089-CORE.
  • Page 14 Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...

  • Page 15: Nvme M.2 Carrier Card And Flash Modules

    Installing an NVMe M.2 carrier card and flash module in the 9009-41A, 9009-42A, or 9223-42H system Find information about installing an NVMe M.2 carrier card and flash module in the IBM Power System S914 (9009-41A), IBM Power System S924 (9009-42A), or IBM Power System H924 (9223-42H) server.
  • Page 16 Figure 1. Removing the power cords from a rack-mounted server 2  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 17 Figure 2. Removing the power cords from a stand-alone server (L003) NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  3...
  • Page 18 4  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 19 Do not pull out more than one drawer at a time. The rack might become unstable if you pull out more than one drawer at a time. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  5...
  • Page 20 5 seconds before you continue with the service process. 6. Remove the service access cover. For a rack-mounted system, complete the following steps. Refer to Figure 4 on page 7. 6  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 21 Slide the cover (B) off the system unit. When the front of the service access cover has cleared the upper frame ledge, lift the cover up and off the system unit. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  7...
  • Page 22 For a stand-alone system, remove the air baffle (A) straight out as shown in Figure 7 on page 10. Place the air baffle upside down on a clean area. 8  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 23 Figure 6. Removing the air baffle from a rack-mounted system NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  9...
  • Page 24 Rotate the top of the clip-in filler until the bottom hook unclasps from the air screen. b) Lift the clip-in filler out of the system. 10  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 25 Figure 8. Removing the air divider c) Lift the air divider up as shown in the following figure. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  11...
  • Page 26 4. Slide one of the new NVMe M.2 flash modules into the NVMe M.2 carrier card socket. See Figure 10 on page 13. Note: There is no plugging sequence when installing two NVMe M.2 flash modules. 12  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 27 Figure 10. Installing an NVMe M.2 flash module 5. Using a Phillips screwdriver, secure the flash module onto the NVMe M.2 carrier card. See Figure 11 on page 14. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  13...
  • Page 28 6. Repeat steps 3 and 4 for the other NVMe M.2 flash module, if needed. 7. Close the black cover on the NVMe M.2 carrier card. 14  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 29 8. Lower the NVMe M.2 carrier card down into the slot. 9. Push in and twist the screws (A) clockwise to fully seat the NVMe M.2 carrier card. See Figure 13 on page 16. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  15...
  • Page 30 For a stand-alone system, replace the air baffle (A) straight into the side of the chassis as shown in Figure 15 on page 18. Ensure that the front flap tucks under the front chassis. 16  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 31 Figure 14. Replacing the air baffle in a rack-mounted system NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  17...

  • Page 32: Installing An Nvme M.2 Carrier Card And Flash Module

    For a rack-mounted system, complete the following steps. Refer to Figure 16 on page 19. a. Slide the cover (A) onto the system unit. b. Close the release latch (B) by pushing it in the direction shown. 18  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 33 For a stand-alone system, complete the following steps. Refer to Figure 17 on page 20. a. Slide the cover (B) on to the system unit as shown. b. Close the latch release (A) by pushing it in the direction shown. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  19...
  • Page 34 Ensure that the cable management arms can move freely. Ensure that the cables at the rear of the unit do not catch or bind as you push the unit into the operating position. 20  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 35 Fasten the power cords (A) to the system using the hook-and-loop fasteners (B) as shown in Figure 19 on page 22 or Figure 20 on page 23. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  21...
  • Page 36 Figure 19. Connecting the power cords to a rack-mounted system 22  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 37 • If you replaced the part because of a service action, verify the installed part. For instructions, see Verifying a repair (www.ibm.com/support/knowledgecenter/POWER9/p9ect/pxect_verifyrepair.htm). • If you installed the part for any other reason, verify the installed part. For instructions, see Verifying the installed part (www.ibm.com/support/knowledgecenter/POWER9/p9haj/pxhaj_hsmverify.htm). NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  23...
  • Page 38 Removing and replacing an NVMe M.2 carrier card and flash module in the 9009-41A, 9009-42A, or 9223-42H system Find information about removing and replacing an NVMe M.2 carrier card and flash module in the IBM Power System S914 (9009-41A), IBM Power System S924 (9009-42A), or IBM Power System H924 (9223-42H) server.
  • Page 39 Figure 21. Removing the power cords from a rack-mounted server NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  25...
  • Page 40 Figure 22. Removing the power cords from a stand-alone server (L003) 26  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 41 NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  27...
  • Page 42 Do not pull out more than one drawer at a time. The rack might become unstable if you pull out more than one drawer at a time. 28  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 43 5 seconds before you continue with the service process. 6. Remove the service access cover. For a rack-mounted system, complete the following steps. Refer to Figure 24 on page 30. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  29...
  • Page 44 Slide the cover (B) off the system unit. When the front of the service access cover has cleared the upper frame ledge, lift the cover up and off the system unit. 30  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 45 For a stand-alone system, remove the air baffle (A) straight out as shown in Figure 27 on page 33. Place the air baffle upside down on a clean area. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  31...
  • Page 46 Figure 26. Removing the air baffle from a rack-mounted system 32  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 47 3. Twist the screws (A) counterclockwise to release the NVMe M.2 carrier card. 4. Lift the NVMe M.2 carrier card out of the slot as shown in Figure 28 on page 34. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  33...
  • Page 48 Lift the black cover on the NVMe M.2 carrier card by pulling up near the pull tab as shown in Figure 29 on page 35. 34  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 49 Figure 29. Lifting the NVMe M.2 carrier card cover b) Using a Phillips screwdriver, unscrew the screw on the NVMe M.2 flash module. See Figure 30 on page 36. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  35...
  • Page 50 Remove the NVMe M.2 flash module by lifting and rotating it as shown in Figure 31 on page 37. d) Repeat these steps for the other flash module, if needed. 36  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 51 Align the clip-in filler over the empty SAS slot. b) Rotate the top of the clip-in filler until the bottom hook clips onto the air screen. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  37...
  • Page 52 Figure 32. Installing the clip-in filler c) Lower the air divider into place as shown in Figure 33 on page 39. 38  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 53 2. Slide one of the new NVMe M.2 flash modules into the NVMe M.2 carrier card socket. See Figure 34 on page 40. Note: There is no plugging sequence when installing two NVMe M.2 flash modules. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  39...
  • Page 54 Figure 34. Installing an NVMe M.2 flash module 3. Using a Phillips screwdriver, secure the flash module onto the NVMe M.2 carrier card. See Figure 35 on page 41. 40  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 55 Figure 35. Securing the NVMe M.2 flash module onto the carrier card 4. Repeat steps 3 and 4 for the other NVMe M.2 flash module, if needed. 5. Close the black cover on the NVMe M.2 carrier card. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  41...
  • Page 56 6. Lower the NVMe M.2 carrier card down into the slot. 7. Push in and twist the screws (A) clockwise to fully seat the NVMe M.2 carrier card. See Figure 37 on page 43. 42  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 57 For a stand-alone system, replace the air baffle (A) straight into the side of the chassis as shown in Figure 39 on page 45. Ensure that the front flap tucks under the front chassis. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  43...
  • Page 58 Figure 38. Replacing the air baffle in a rack-mounted system 44  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...

  • Page 59: Removing And Replacing An Nvme M.2 Carrier Card And Flash Module

    For a rack-mounted system, complete the following steps. Refer to Figure 40 on page 46. a. Slide the cover (A) onto the system unit. b. Close the release latch (B) by pushing it in the direction shown. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  45...
  • Page 60 Slide the cover (B) on to the system unit as shown. b. Close the latch release (A) by pushing it in the direction shown. 46  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 61 Ensure that the cable management arms can move freely. Ensure that the cables at the rear of the unit do not catch or bind as you push the unit into the operating position. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  47...
  • Page 62 Fasten the power cords (A) to the system using the hook-and-loop fasteners (B) as shown in Figure 43 on page 49 or Figure 44 on page 50. 48  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 63 Figure 43. Connecting the power cords to a rack-mounted system NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  49...
  • Page 64 • If you replaced the part because of a service action, verify the installed part. For instructions, see Verifying a repair (www.ibm.com/support/knowledgecenter/POWER9/p9ect/pxect_verifyrepair.htm). • If you installed the part for any other reason, verify the installed part. For instructions, see Verifying the installed part (www.ibm.com/support/knowledgecenter/POWER9/p9haj/pxhaj_hsmverify.htm). 50  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...

  • Page 65: Removing An Nvme M.2 Carrier Card And Flash Module

    Permanently removing an NVMe M.2 carrier card and flash module from the 9009-41A, 9009-42A, or 9223-42H system Find information about permanently removing an NVMe M.2 carrier card and flash module from the IBM Power System S914 (9009-41A), IBM Power System S924 (9009-42A), or IBM Power System H924 (9223-42H) server.
  • Page 66 Figure 45. Removing the power cords from a rack-mounted server 52  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 67 Figure 46. Removing the power cords from a stand-alone server (L003) NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  53...
  • Page 68 54  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 69 Do not pull out more than one drawer at a time. The rack might become unstable if you pull out more than one drawer at a time. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  55...
  • Page 70 5 seconds before you continue with the service process. 6. Remove the service access cover. For a rack-mounted system, complete the following steps. Refer to Figure 48 on page 57. 56  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 71 Slide the cover (B) off the system unit. When the front of the service access cover has cleared the upper frame ledge, lift the cover up and off the system unit. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  57...
  • Page 72 For a stand-alone system, remove the air baffle (A) straight out as shown in Figure 51 on page 60. Place the air baffle upside down on a clean area. 58  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 73 Figure 50. Removing the air baffle from a rack-mounted system NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  59...
  • Page 74 3. Twist the screws (A) counterclockwise to release the NVMe M.2 carrier card. 4. Lift the NVMe M.2 carrier card out of the slot as shown in Figure 52 on page 61. 60  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 75 Figure 52. Removing the NVMe M.2 carrier card 5. Lift the NVMe M.2 carrier card out of the slot as shown in Figure 52 on page 61. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  61...
  • Page 76 Lift the black cover on the NVMe M.2 carrier card by pulling up near the pull tab as shown in Figure 54 on page 63. 62  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 77 Figure 54. Lifting the NVMe M.2 carrier card cover b) Using a Phillips screwdriver, unscrew the screw on the NVMe M.2 flash module. See Figure 55 on page 64. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  63...
  • Page 78 Remove the NVMe M.2 flash module by lifting and rotating it as shown in Figure 56 on page 65. d) Repeat these steps for the other flash module, if needed. 64  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 79 Align the clip-in filler over the empty SAS slot. b) Rotate the top of the clip-in filler until the bottom hook clips onto the air screen. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  65...
  • Page 80 Figure 57. Installing the clip-in filler c) Lower the air divider into place as shown in Figure 58 on page 67. 66  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 81 For a stand-alone system, replace the air baffle (A) straight into the side of the chassis as shown in Figure 60 on page 69. Ensure that the front flap tucks under the front chassis. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  67...
  • Page 82 Figure 59. Replacing the air baffle in a rack-mounted system 68  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...

  • Page 83: Permanently Removing An Nvme M.2 Carrier Card And Flash Module

    For a rack-mounted system, complete the following steps. Refer to Figure 61 on page 70. a. Slide the cover (A) onto the system unit. b. Close the release latch (B) by pushing it in the direction shown. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  69...
  • Page 84 Slide the cover (B) on to the system unit as shown. b. Close the latch release (A) by pushing it in the direction shown. 70  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 85 Ensure that the cable management arms can move freely. Ensure that the cables at the rear of the unit do not catch or bind as you push the unit into the operating position. NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  71...
  • Page 86 Fasten the power cords (A) to the system using the hook-and-loop fasteners (B) as shown in Figure 64 on page 73 or Figure 65 on page 74. 72  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 87 Figure 64. Connecting the power cords to a rack-mounted system NVMe M.2 carrier card and flash modules for the 9009-41A, 9009-42A, or 9223-42H  73...
  • Page 88 • If you replaced the part because of a service action, verify the installed part. For instructions, see Verifying a repair (www.ibm.com/support/knowledgecenter/POWER9/p9ect/pxect_verifyrepair.htm). • If you installed the part for any other reason, verify the installed part. For instructions, see Verifying the installed part (www.ibm.com/support/knowledgecenter/POWER9/p9haj/pxhaj_hsmverify.htm). 74  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...

  • Page 89: Related Procedures

    For details, see Removing an operational NVMe device from a partition in the IBM i Knowledge Center. Note: To navigate to the page in the IBM i 7.4 Knowledge Center, select Systems management > Disk management > Disk management checklist > Removing an operational NVMe device from a partition.
  • Page 90 76  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...

  • Page 91: Notices

    Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead.

  • Page 92: Privacy Policy Considerations

    International Business Machines Corp., registered in many jurisdictions worldwide. Other product and service names might be trademarks of IBM or other companies. A current list of IBM trademarks is available on the web at Copyright and trademark information.
  • Page 93 Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung von IBM verändert bzw.
  • Page 94 This statement applies to products greater than 20 A, single phase. This statement applies to products greater than 20 A per phase, three-phase. Japan Voluntary Control Council for Interference (VCCI) Notice Korea Notice 80  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 95 Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Proper cables and connectors are available from IBM-authorized dealers. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.

  • Page 96: Class B Notices

    Armonk, New York 10504 Tel: 914-499-1900 Der verantwortliche Ansprechpartner des Herstellers in der EU ist: IBM Deutschland GmbH Technical Relations Europe, Abteilung M456 IBM-Allee 1, 71139 Ehningen, Germany 82  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
  • Page 97 Tel: +49 (0) 800 225 5426 email: HalloIBM@de.ibm.com Generelle Informationen: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55032 Klasse B Japan Electronics and Information Technology Industries Association (JEITA) Notice This statement applies to products less than or equal to 20 A per phase.

  • Page 98: Terms And Conditions

    Permissions for the use of these publications are granted subject to the following terms and conditions. Applicability: These terms and conditions are in addition to any terms of use for the IBM website. Personal Use: You may reproduce these publications for your personal, noncommercial use provided that all proprietary notices are preserved.
  • Page 99 IBM reserves the right to withdraw the permissions granted herein whenever, in its discretion, the use of the publications is detrimental to its interest or, as determined by IBM, the above instructions are not being properly followed. You may not download, export or re-export this information except in full compliance with all applicable laws and regulations, including all United States export laws and regulations.
  • Page 100 86  Power Systems: NVMe M.2 carrier cards and flash modules for the 9009-41A, 9009-42A, or 9223-42H...
