Technical Specifications - E.T. Systems DC BLUE ADVANCED Installer's Instructions

Installation:
•
Remov e all cables, latches/locks or catches not necessary for automation.
o
Ensure the working area is clear of obstructions and obstacles.
o
Install the door sticker depicting the safety rev erse test and keeping door area clear. This sticker should
o
be fixed to the inside surface of the door or near any permanent door control switches such as a wall
console if installed.
The emergency release cord must be installed where it is no higher than 1.8m from the floor lev el.
o
Any additional fixed door control switches such as wall consoles, if installed, must be at a height of at
o
least 1,5m, within clear sight of the door and away from any mov ing components of the system.
Do not substitute any component of DC Blue Adv anced with any other manufacturer's part. ET
o
Systems accepts no responsibility for the safety and correct operation of the automation system if any
of these points are ignored.
After Installation: It is the responsibility of the installer to ensure the user:
•
Is proficient in the use of the manual emergency release mechanism.
o
Is issued with the documentation accompanying this product.
o
Understands that the door may not be operated out of clear sight.
o
Ensures that children are kept clear of the door area and that children do not play with the remote
o
transmitters.
Is instructed not to attempt to repair or adjust the automation system and to be aware of the danger
o
of continuing to use the automation system in an unsafe condition before a serv ice provider attends to
it.
Is proficient in testing the unit's safety obstruction sensing system by means of placing a 40mm high
o
object (wooden block) below the door in the closed position. On contact with the object the unit must
rev erse the door away and back to the open position.
Primary power supply
Power consumption
Motor voltage
Maximum operations per day
Traveller speed*
Operating temperature range
Anti-crushing safety sensing
Auxiliary supply output
Rated battery charging voltage
Built in receiver format
Receiver frequency
Memory
Applicable door types
Drawbar options(Ex-stock)
Applicable door sizes
* Based on the assumption that the door is balanced correctly and moving freely.
ET DC BLUE ADVANCED INSTALLER 2012.025.12.05.2014

TECHNICAL SPECIFICATIONS

220 – 240Vac @ 50hz
120W peak @ (220 -240vac)
24V dc
50 full cycles per 24hrs @ a rate of Max. 2 per hour
8m/min
-10 to 50° C (14F to 122F)
Yes - Electronic digital profiling
24Vdc @ 250mA peak or 150mA continuous
27.5Vdc
ET BLU MIX © enhanced rolling code.
433.92Mhz
EEPROM
One piece trackless tip-up or multiple panel sectional
overhead doors
2.2m or 3.2m or 3.7m
<13m²
www.et.co.za
