Learning A Transmitter Code In The Receiver Memory - E.T. Systems DC BLUE ADVANCED Installer's Instructions

NB!! The built in receiver will only work with the ET BLU MIX © enhanced rolling code or ET BLUE rolling code
To enter the Program
menu. Press and hold SET
button until buzzer beeps
twice.
Select receiver setup by
scrolling up with the UP
button until "r" flashes.
Press and release SET
button to enter receiver
programming.
Press and release the UP
or DOWN buttons to scroll
to the channel the remote
button must be learnt into.
Press and hold desired
remote button.
While still holding the
desired remote button,
press and release the
"SET" button.
Release the remote
button
Scroll up or down
to next program
option.
ET DC BLUE ADVANCED INSTALLER 2012.025.12.05.2014

LEARNING A TRANSMITTER CODE IN THE RECEIVER MEMORY.

Max users (BT) button trigger channel = 35 user codes
Max users (LT) courtesy light trigger channel = 5 user codes
From Standby Mode
Action
transmitters.
Display begins flashing "P"
and buzzer beeps twice
to confirm the main
program menu is active.
Display flashes "r" to
confirm receiver
programming menu is
selected.
Buzzer beeps once and
"b" for (BT) is displayed.
b = (BT) button trigger
channel.
L = (LT) Courtesy light
trigger channel.
LED on remote transmitter
illuminates.
"1" on display and 1 beep
= user code successfully
learnt.
"2" on display and 2
beeps = user code
already in the receiver
memory.
"3" on display and 3
beeps = Unsuccessful
because no code was
seen within 4 sec of the
SET button being pressed.
Mandatory timeout.
"F" on display and
multiple rapid beeps =
Memory full
The display returns to
flashing "r". Receiver
programming menu.
Press and release EXIT to
OR
return to Standby mode.
19
www.et.co.za
Response
or
Successful
Code already in
memory
Unsuccessful
Memory full
