Press and release either
the remote button
trigger or the hardwired
trigger.
On reaching the full
open position, the auto-
close timer times out the
previously programmed
auto-close time.
20 sec. for example.
Interrupt the safety
beams.
Safety beam still
interrupted.
Any further closing
triggers while beams are
still interrupted.
ET DC BLUE ADVANCED INSTALLER 2012.025.12.05.2014
ADVANCED OPERATING FEATURES
Auto-close feature.
Action
ADVANCED FEATURES
Safety beam input
NB!! This input only affects the closing cycle.
Action
Door in the closed
position.
Courtesy light off.
Door begins opening
and courtesy light
switches on.
Courtesy light and
buzzer, flashes and
sounds three times,
before door begins
closing automatically.
Door closing.
Light on.
Display shows "b", door
stops and begins
opening once again.
Light remains on.
Door reaches full open
position. Display
continues to show "b" as
long as the safety
beams are interrupted.
Light switches off after
3min.
Door will not close.
Display continues to
show "b" as long as the
safety beams are
interrupted and buzzer
beeps once.
29
www.et.co.za
Response
X 3
Response
