Example 1. Simply opening the door fully and closing the door again fully.
Press and release either
the remote button
trigger or the hardwired
trigger.
Wait for door to reach
the full open position.
Press and release either
the remote button
trigger or the hardwired
trigger.
Wait for door to reach
the closed position.
ET DC BLUE ADVANCED INSTALLER 2012.025.12.05.2014

BASIC OPERATING FEATURES

Basic open and close triggers using the (BT) button trigger.
Action
Door in the closed
position.
Courtesy light off.
Door begins opening
and courtesy light
switches on.
Door stops and waits in
the open position.
Courtesy light remains
on for a further 3
minutes.
Door begins closing and
if the courtesy light had
previously timed out and
switched off, it will switch
on again for three
minutes.
Door stops in the closed
position. Light remains
on until three minute
timer has expired.
23
www.et.co.za
Response
