UMPETHA 082009/072010.014 Table of contents Page Category Introduction Safety obligations and general warnings Identification of components Technical specifications Before installing preparation Cable requirements Hardware installation Accessing manual override and remov ing cov er Installing the baseplate and positioning motor Inserting or remov ing battery and mounting of motor to baseplate...
Page 3
UMPETHA 082009/072010.014 WARNING TO THE INSTALLER. GENERAL SAFETY OBLIGATIONS. Caution! It is important for personal safety to follow all the instructions carefully. Incorrect installation or misuse may cause serious personal harm. Keep the instructions in a safe place for future reference.
Page 4
UMPETHA 082009/072010.014 1. Plug in terminal connectors 13. Motor mounting slot 2. Control card 14. Manual override cam sensor magnet 3. Control card holder 15. Gearbox housing 4. Battery 16. Manual override cam reed switch sensor 5. Antenna 17. DC to DC switch-mode 12V Aux supply module (300mA peak) 6.
UMPETHA 082009/072010.014 TECHNICAL SPECIFICATIONS 29Vac 1Amp plug-in transformer model POWER SUPPLY @ GATE REQUIREMENT 220Vac for built in transformer model MAXIMUM ABSORBED CURRENT @ 220V AC SUPPLY 100mA MOTOR VOLTAGE 24Vdc MAXIMUM STARTING RESISTANCE OF GATE < 10kgF set MAXIMUM RUNNING RESISTANCE OF GATE <...
Page 6
UMPETHA 082009/072010.014 BEFORE ATTEMPTING TO INSTALL A SLIDE GATE OPERATOR, PLEASE BE CERTAIN YOU HAVE READ AND UNDERSTOOD THE FOLLOWING TO ENSURE CONTINUED SATISFACTORY SAFE SERVICE FROM THIS PRODUCT: The following are points to note before installing your new slide gate operator: 1.
Page 7
UMPETHA 082009/072010.014 CABLING REQUIREMENTS Before mounting the operator ensure your cabling and conduiting are in place to prevent any inconvenience at a later stage. Allow for spare cabling in case of faulty cable & breakages (especially important when using low specification cable). If installing an intercom, remember to allow for sufficient cable cores for all the uses on the system as per manufacturers cabling requirements.
Page 8
UMPETHA 082009/072010.014 Manually overriding the gearbox and removing the cover Unlocked and Locked and engaged Unlocked and engaged disengaged Insert key and turn clockwise. Remember to pull or push the gate gently until the gears “click” re-engage, before running the motor after a manual override.
Page 9
UMPETHA 082009/072010.014 Motor positioning to gate. Hot tip: Cast the track plinth at the same time as the motor plinth 30 to 50mm between the proudest part of the gate and the edge of the base plate Guide post Top view 300mm Install the base plate on the protected side of the driveway wherever possible.
Page 10
UMPETHA 082009/072010.014 Inserting and removing the battery Please note! In the cases where something like the gate guide post or a wall is obstructing the battery from being angled to one side, making it impossible to insert or remove the battery...
UMPETHA 082009/072010.014 Installing the rack. Rack to pinion spacing. Rack to pinion spacing. To tight. Rack to pinion spacing. Correct. Space to large. This will cause unwanted rolling The driving surfaces of each tooth This will cause skipping at the resistance especially in colder are 1 to 2mm apart.
Page 12
UMPETHA 082009/072010.014 If satisfied with the rack level fasten the first “TEK” screw (supplied) in the middle of the slot nearest the closing edge of the gate. Move the gate towards the open position. Far enough that you can access the last mounting slot at the opposite end of the length of rack to the end already fastened.
UMPETHA 082009/072010.014 Installing the limit actuator (Mandatory before programming) Push the gate up against the closed stopper/keep. Place magnetic actuator on top of the rack where it is half way across the reed switch. See below Remove the rack screw (Holding the nylon teeth to the steel angle) closest to the middle of the slot in the actuator.
UMPETHA 082009/072010.014 Runtime Setup The run- time routine must be completed before attempting to continue with any other routine! The closed limit actuator must be installed correctly before starting this routine! Action Response Gate midway and engaged. Program jumper on 2 beeps All dip-switches off.
UMPETHA 082009/072010.014 Auto-close time:- (Default = 15sec.) NB! The auto-close mode type must be selected after all programming is completed. (See operating mode selection on page 24) Action Response Program jumper on 2 beeps Dip-switch 1 on 1 beep = 1sec.
Page 17
UMPETHA 082009/072010.014 Pedestrian opening distance and independent pedestrian auto-close time:- (Default = ± 1m opening and 5sec. auto-close time) Action Response Gate midway and engaged 1. Program jumper on 2 beeps 2. Dip-switch 2 on 3. Press and release Set button Gate closes 4.
UMPETHA 082009/072010.014 Changing crawl distance:- Default: - 350mm Action Response Program jumper on 2 beeps Dip-switch 4 on Beeps confirm change Press and release Set button 1 beep = 350mm 2 beeps = 700mm Continuous beep Dip-switch 4 off Continuous beep off To change again without leav ing programming, repeat from point 2.
Page 19
UMPETHA 082009/072010.014 Changing switch type for safety beam input:- Default:- Normally open Action Response Program jumper on 2 beeps Dip-switch 1 and 2 on Beeps confirm change Press and release Set button 1 beep = N/C 2 beeps = N/O (Default)
Page 20
It will however stop at the point of impact with the closed catch and emit a 5sec long beep tone. At the next valid opening trigger the UMPETHA will re-emit the 5sec long beep tone and only open the gate by ±1 meter. This will allow for the user to be able to enter the property and manually override the gate.
UMPETHA 082009/072010.014 Receiver programming: - Master erase; Action Response All power off Short both PED (pedestrian) and BT (full opening) pins to center pin (Use the key-ring supplied with the transmitters to do this as shown here) RX (receiv er) LED flashes rapidly - Power up stops flashing - on continuously.
Page 22
UMPETHA 082009/072010.014 Learning a remote transmitter button in the receiver for BT open/close operation: - (25 user memory) Action Pictorial confirmation Response Press and hold the required remote RX LED flickers lightly. transmitter button RX LED flashes Confirmation. Short circuit the middle RX 1 flash = First transmitter learnt.
Page 23
UMPETHA 082009/072010.014 Learning a TX button for BT (Full opening) operation using the RX (receiver) Master remote: - (25 user memory) The RX (receiv er) Master remote can only be learnt into memory using the RX (receiv er) pins! The RX (receiv er) Master remote is the first remote learnt into the BT (full opening) memory and it must be able to operate the PED(pedestrian) function of the built-in RX (receiv er) as well.
UMPETHA 082009/072010.014 Operating mode selection (Program jumper off) Dip-switch selection Mode All off Standard (Four step logic) When the motor is activ ated using any BT (full opening) input the gate will open or close and can be stopped in mid cycle using any BT (full opening) input again.
UMPETHA 082009/072010.014 Dip-switch selection Mode Complex Auto-close/Condominium Dip-switch 2 ON (only) (select when using a loop detector) In this mode any BT (full opening) input trigger is treated as an opening trigger. On reaching the full open position the unit times out the pre-programmed auto-close time after which it will begin closing the gate.
UMPETHA 082009/072010.014 Additional functions Holiday lock-out Av ailable in all but Complex Auto-close mode. Action Response Close gate Press and hold the PED (pedestrian) Until 5sec beep begins. button on a master remote Release PED (pedestrian) button on Beeping will continue until confirmation or master remote 5sec expires.
UMPETHA 082009/072010.014 Auto-close override Party mode Av ailable in all but Complex Auto-close mode. Action Response With the gate at any open position Press and hold any TX (transmitter) After 5sec unit will emit Multiple rapid BT (full opening) button beeps to confirm.
Page 28
UMPETHA 082009/072010.014 Courtesy light out Available in all modes. The courtesy light output will activ ate on any opening trigger (BT or Pedestrian). The light output will remain on until three minutes after the gate has re-closed. Program Response Beeps...
UMPETHA 082009/072010.014 WARRANTY: All goods manufactured by G&C Electronics cc T/A ET Systems carry a 12 month factory warranty from date of invoice. All goods are warranted to be free of faulty components and manufacturing defects. Faulty goods will be repaired or replaced at the sole discretion of ET Systems free of charge.
