SOAD
monitor
monitor
Page 6
(4) M4 x 10 (mm)
phillip screws
Figure 1. Single Stud Installation
(4) M4 x 10 (mm)
phillip screws
Figure 2. Solid Structure Installation
(4) M6 x 12 (mm)
phillip screws
BACK PLATE
FLAT
WASHERS
(4) #14 X 2"
LAG BOLTS
SOAD
SWING OUT
ARM
(4) M6 x 12 (mm)
phillip screws
BACK PLATE
(4) 1/4" X 2"
ANCHOR BOLTS
SOAD
SWING OUT
ARM
WOOD STUD
WALL STRUCTURE
Installation Instructions
