Premier Mounts Universal Tabletop Stand PSD-TTS Dimensional Drawing

8 7

Dimensions shown in inches and (mm)

D
C
6
B

NOTES:

*1 - PSD-TTS (ACRYLIC) BASE
PSD-TTS/C (MDF) BASE
*2 - Mounting brackets
*3 - Cable access hole
*4 - Cover
*5 - Vertical brackets
*6 - Gripplates
™

BID SPECIFICATIONS

CONSTRUCTION OF THE UPPER ASSEMBLY 12 (ga) CRS

PSD-TTS (MDF) BASE OR PSD-TTS/C (Acrylic) BASE
A
ALL SHARP EDGES ARE BROKEN FOR A SMOOTH FINISH
DRAWINGS ARE INTERPRET BY (Y14.5)
8
7
6
32.000
(812.8)
30.000
(762)
1
31.300
(795.02)
8.270
1.250
(210.06)
(31.75)
5
(493.78)
Ø1.500
(38.1)
3
4
1.500
(38.1)
6
5 4
13.000
(330.2)
2
3.817
(96.95)
19.44 20.000
(508) 23.251
(590.5)
1.000
13.000
(25.4)
(330.2)
4
5
3 2
27.751
(704.8)
