INSTALLATION INSTRUCTIONS
SHLF-EQ
Single Equipment Shelf for Low Profile Flat-Panel Mounts
NORTH AMERICA
EUROPE
3130 East Miraloma Avenue
Swallow House,
Anaheim, CA 92806 USA
Shilton Industrial Estate,
Shilton, Coventry, England CV79JY
USA and Canada
Phone: +44 (0) 2476 614700
Phone: 1.800.368.9700
Fax: 1.800.832.4888
Fax: +44 (0) 2476 614710
Other Locations
Phone: (001).714.632.7100
Fax: (001).714.632.1044
9533-042-001-00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Premier Mounts SHLF-EQ
Summary of Contents for Premier Mounts SHLF-EQ
- Page 1 INSTALLATION INSTRUCTIONS SHLF-EQ Single Equipment Shelf for Low Profile Flat-Panel Mounts NORTH AMERICA EUROPE 3130 East Miraloma Avenue Swallow House, Anaheim, CA 92806 USA Shilton Industrial Estate, Shilton, Coventry, England CV79JY USA and Canada Phone: +44 (0) 2476 614700 Phone: 1.800.368.9700 Fax: 1.800.832.4888...
-
Page 2: Table Of Contents
Premier Mounts does not warrant against damage caused by the use of any Premier Mounts product for purposes other than those for which it was designed or damage caused by unauthorized attachments or... -
Page 3: Installation Tools
Tape Measure Level Parts List Make sure your Premier Mounts product has the following hardware and components before beginning installation. If there are parts missing and/or damaged, stop the installation and call Premier Mounts at (800) 368-9700. SHLF-EQ Hardware Large Shelf... -
Page 4: Features
The Single Equipment Shelf for Low Profile Flat-Panel Mounts (SHLF-EQ) is a versatile shelving system designed for Premier Mounts’ P-Series mounts, one of the thinnest low profile flat-panel mounts on the market. The SHLF-EQ is the perfect solution for “daisy-chaining” A/V equipment and/or computers below the flat-panel display. -
Page 5: Installing The Shlf-Eq
Installing the SHLF-EQ Introduction The SHLF-EQ single equipment shelf is designed to easily hook into Premier Mounts’ P-Series mounts. It permits the user to adjust the shelf in 10 increments of 1.3”. Combine additional A/V shelf components in different configurations depending on your needs. Additional shelves (SHLF-VE, SHLF-VC, SHLF-XE) are not included. -
Page 6: Using The Equipment Strap
Adjustable bracket not shown. Insert the equipment strap through the shelf’s side slots (C) and use it to keep the video conferencing camera or other equipment safely in place. Page 6 Installation Instructions Visit the Premier Mounts website at http://www.premiermounts.com... -
Page 7: Attaching Additional Shelves (Optional)
Step 2 SHLF-XE M6 x 8mm pan combo screws Use four (4) M6 x 8mm pan combo screws to fasten the additonal large shelf to the shelf extension bracket. Installation Instructions Page 7 Visit the Premier Mounts website at http://www.premiermounts.com... - Page 8 Re-insert the bottom two (2) M6 x 8mm pan combo screws from Step 1 to fasten both assemblies together. Step 5 Attach additional shelves by repeating Steps 1 to 4 (attach each additional shelf to the lowest shelf in the assembly). Page 8 Installation Instructions Visit the Premier Mounts website at http://www.premiermounts.com...
-
Page 9: Using Different Combos
Combine additional A/V shelf components in different configurations depending on your needs. Additional shelves (SHLF-VE, SHLF-VC, SHLF-XE) are not included. Technical Specifications All measurements are in inches [mm]. 1.33 4.00 17.92 25.00 2.62 19.75 19.75 1.88 3.00 Installation Instructions Page 9 Visit the Premier Mounts website at http://www.premiermounts.com... -
Page 10: Warranty
What Premier Mounts Will Do At the sole option of Premier Mounts, Premier Mounts will repair or replace any product or product part that is defective. If Premier Mounts chooses to replace a defective product or part, a replacement product or part will be shipped to you at no charge, but you must pay any labor costs.
