Alarm - Fluidwell F Series Operation Manual

Page 14
With these settings, it is determined how the level will be monitored and the functionality of the
transistor / relay outputs be determined.
Please be aware that the alarm levels can be programmed at operator level as well. Moreover, the
function be locked (setup 32).
Note: for transistor / relay output functions: read SETUP 8 "relays".
EMPTY
21
ALARM VALUE
LOW - LOW
32
ALARM VALUE
LOW
33
ALARM VALUE
HIGH
34
ALARM VALUE
HIGH - HIGH
35
DELAY TIME ALARM
LOW - LOW
36
DELAY TIME ALARM
LOW
37
DELAY TIME ALARM
HIGH
38
DELAY TIME ALARM
HIGH - HIGH
39

2 - ALARM

When the level is zero, then it is possible to ignore or disable the level
monitoring. The following settings can be selected:
DEFAULT: in case of a low-level alarm and level zero, it will switch
the alarm output and indicate the alarm on the display.
NO RELAY: in case of a low-level alarm and level zero, it won't switch
the alarm output but will indicate the alarm on the display
only.
IGNORE: in case of a low-level alarm and level zero, it won't switch
the alarm output and nothing will be indicated on the
display.
The low-low alarm is set with this setting. An alarm will be generated as
long as the level is lower as this value.
The low alarm is set with this setting. An alarm will be generated as long
as the level is lower as this value.
The high alarm is set with this setting. An alarm will be generated as long
as the level is higher as this value.
The high-high alarm is set with this setting. An alarm will be generated as
long as the level is higher as this value.
An alarm generated by SETUP 32 "low-low" can be ignored during X-time
period. If the actual level is still incorrect after this delay time, then an
alarm will be generated.
An alarm generated by SETUP 33 "low" can be ignored during X-time
period. If the actual level is still incorrect after this delay time, then an
alarm will be generated.
An alarm generated by SETUP 34 "high" can be ignored during X-time
period. If the actual level is still incorrect after this delay time, then an
alarm will be generated.
An alarm generated by SETUP 35 "high-high" can be ignored during X-
time period. If the actual level is still incorrect after this delay time, then an
alarm will be generated.
HF173AEN_v0501_05
