3.2.2.

OVERVIEW FUNCTIONS SETUP LEVEL

1 LEVEL
11 UNIT
12 DECIMALS
13 SPAN
14 DECIMALS SPAN
15 OFFSET
2 ALARM
21 EMPTY
22 ALARM LOW-LOW
23 ALARM LOW
24 ALARM HIGH
25 ALARM HIGH-HIGH
26 DELAY ALARM low-low
27 DELAY ALARM LOW
28 DELAY ALARM HIGH
29 DELAY ALARM high-high
3 DISPLAY
31 FUNCTION
32 ALARM SET
4 POWER MANAGEMENT
41 LCD UPDATE
42 BATTERY MODE
5 SENSOR
51 FILTER
52 CUT-OFF
53 CALIBRATE LOW
54 CALIBRATE HIGH
6 LINEARISATION
61 % / M-FACTOR 1
62 % / M-FACTOR 2
.. ..
6F % / M-FACTOR 15
6G LINEARISATION
7 ANALOG
71 OUTPUT
72 LEVEL MINIMUM
73 LEVEL MAXIMUM
74 CUT-OFF
75 TUNE MIN - 4mA / 0V
76 TUNE MAX- 20mA / 10V
77 FILTER
8 RELAYS
81 OUTPUT R1
82 OUTPUT R2
83 OUTPUT R3
84 OUTPUT R4
9 COMMUNICATION
91 SPEED / BAUDRATE
92 ADDRESS
93 MODE
A OTHERS
A1 TYPE / MODEL
A2 SOFTWARE VERSION
A3 SERIAL NO.
A4 PASSWORD
A5 TAGNUMBER
SETUP FUNCTIONS AND VARIABLES
mL - L - m3 - mg - g - kg - ton - GAL - bbl - lb - cf - REV -
no unit
0 - 1 - 2 - 3 (Ref: displayed value)
0.000001 - 999,999 unit
0 - 6
-999,999 - +999,999 units
default - no relays - ignore
0000.000 - 999,999
0000.000 - 999,999
0000.000 - 999,999
0000.000 - 999,999
0.1 - 999.9 seconds
0.1 - 999.9 seconds
0.1 - 999.9 seconds
0.1 - 999.9 seconds
span - percentage
operator - setup
fast - 1 sec - 3 sec - 15 sec - 30 sec - off
operational - shelf
00 - 99
0.0 - 99.9%
(0)4mA
20mA
0.01% – 99.99% / 0 – 9.999999
0.01% – 99.99% / 0 – 9.999999
........
0.01% – 99.99% / 0 – 9.999999
enable / disable
disable - enable
000.000 - 999,999
000.000 - 999,999
0.0 - 9.9%
0 - 9,999
0 - 9,999
00 - 99
low-low - low - high - high-high - all - off
low-low - low - high - high-high - all - off
low-low - low - high - high-high - all - off
low-low - low - high - high-high - all - off
1200 - 2400 - 4800 - 9600
1 - 255
RTU - off
F173-A
----------
----------
0000 - 9999
0000000 - 9999999
HF173AEN_v0501_05
