Unit Dimensions - Generac Power Systems Magnum Series Operating Manual

General Information

Unit Dimensions

A
A
MMG130 DI4 /175 DI4 /205 DI4 -
Skid Mounted
MMG130 DI4 /175 DI4 /205 DI4 -
Trailer Mounted
Specifications are subject to change without notice.
8
B
B
Figure 2-1. Unit Dimensions
A
50 in. (1.27 m)
86 in. (2.18 m)
MMG130DI4/175DI4/205DI4 Operating Manual
C
C
B
77 in. (1.96 m)
93 in. (2.36 m)
02069
C
144 in. (3.66 m)
210 in. (5.33 m)
33722 D
