standard grease gun on the lubrication point found on the side of the jack near the crank. Rotate the jack
handle to distribute the grease evenly.
• A lightweight oil must be applied to the handle unit at both sides of the tube.
• If equipped, the axle bolt and nut assembly of the caster wheel must also be lubricated with the same
lightweight oil.

Top-Wind Models

• Apply a lightweight oil to the screw stem.
Oil Grease

TRAILER WHEEL BEARINGS

The trailer axles are equipped with a grease fitting to allow lubrication of the wheel bearings without the need to
disassemble the axle hub. To lubricate the axle bearings, remove the small rubber plug on the grease cap, attach a
standard grease gun fitting to the grease fitting and pump grease into the fitting until new grease is visible around
the nozzle of the grease gun. Use only a high quality grease made specifically for lubrication of wheel bearings. Wipe
any excess grease from the hub with a clean cloth and replace the rubber plug when finished. The minimum
recommended lubrication is every 12 months or 12,000 miles (19,312 km). More frequent lubrication may be required
under extremely dusty or damp operating conditions.
33722 D
Grease
Grease
Oil
Figure 4-1. Apply Oil
MMG130DI4/175DI4/205DI4 Operating Manual
Oil
Oil
Maintenance
Oil
00243
