MESH FILTERS

NOTE: prior to use, remove protective film from the filter frame.
1. To remove the aluminum mesh filter, pull down on latch tab to disengage the filter from the hood.
Tilt the filter downward and remove.
2. To install the alumimum mesh filter, align rear filter tabs with slots in the hood. Pull latch tab
down. Push filter into place and release tab. Make sure the filter is securely engaged after installation.
Model ALU-E43
Model ALU-E63
- 25 -
FIG. 30
