Disassembly

Disassembly Steps

The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the Battery:
1. Remove the battery
2. Install the battery
To remove the Rear Top Cover:
1. Remove the rear top cover
To remove the Hard Disk Drive:
1. Remove the rear top cover
2. Remove the HDD
To remove the Optical Device:
1. Remove the rear top cover
2. Remove the optical device
To remove and install the System Memory:
1. Remove the rear top cover
2. Remove the system memory
To remove the Stand:
1. Remove the rear top cover
2. Remove the stand
2 - 4 Disassembly Steps
To remove the WLAN Module:
page 2 - 5 1. Remove the rear top cover
page 2 - 6 2. Remove the WLAN module
To remove the CPU:
page 2 - 7 1. Remove the rear top cover
2. Remove the CPU
3. Install the CPU
page 2 - 7
page 2 - 8
page 2 - 7
page 2 - 13
page 2 - 7
page 2 - 14
page 2 - 7
page 2 - 16
page 2 - 7
page 2 - 17
page 2 - 7
page 2 - 18
page 2 - 20
